• Cisco AIR-ANT2588P3M-N antenna on gray rounded cutting board
1 1

Cisco

Cisco AIR-ANT2588P3M-N | Aironet Dual-Band 8 dBi Patch Antenna, 3x N-Type

AIR-ANT2588P3M-N

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aironet AIR-ANT2588P3M-N is a dual-band directional patch antenna for Cisco access points and industrial routers with external antenna ports. It covers both the 2.4 GHz and 5 GHz bands with 8 dBi peak gain, making it a good fit for outdoor Wi-Fi deployments that need focused coverage, such as campus areas, industrial sites, and point-to-multipoint or mobile and rugged networking.

The antenna is a 3-element dual-polarised patch design with three N-Female bulkhead connectors, so it suits 3-antenna-port (MIMO) access points. It operates across 2400-2500 MHz and 5150-5900 MHz, with a 30 degree elevation and 120 degree azimuth 3-dB beamwidth, a VSWR of 2:1 or less and a 50 Ohm nominal impedance. The enclosure is rated IP67 and operates from -40 to 55 C. It is a passive antenna, so no power is required.

It is intended for Cisco access points and industrial routers with external N-type antenna ports, including Aironet 1560 and 1570 external-antenna models and the Catalyst IR1100 Rugged Series. Check the antenna port count and connector type of your access point before ordering.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dual-band operation covering both 2.4 GHz and 5 GHz Wi-Fi
- 3-port design supports 3-antenna-port (MIMO) access points
- Directional patch pattern for focused coverage
- Dual-polarised elements
- Outdoor-rated IP67 enclosure with a wide operating temperature range
- Passive antenna that needs no power
- Pole or wall mounting per the installation guide

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Antenna type: 3-element dual-polarised patch
- Operating frequency range: 2400-2500 MHz and 5150-5900 MHz
- Peak gain: 8 dBi (both bands)
- Polarisation: Linear, dual
- Nominal input impedance: 50 Ohms
- VSWR: 2:1 or less
- Elevation plane 3-dB beamwidth: 30 degrees
- Azimuth plane 3-dB beamwidth: 120 degrees
- Sidelobe level: < -20 dBc
- Front-to-back ratio: > 10 dB
- Connector type: N-Female bulkhead (x3)
- Length: 12 in. (30.48 cm)
- Width: 7 in. (17.78 cm)
- Height: 1.1 in. (2.79 cm)
- Weight: 16 oz. (0.45 kg)
- Operating temperature: -40 to 55 C (-40 to 131 F)
- Environmental rating: IP67

FAQs

Q: Which access points is this antenna designed for?
A: It is designed for Cisco access points and industrial routers with external N-type antenna ports, including Aironet 1560 and 1570 external-antenna models and the Catalyst IR1100 Rugged Series. Confirm your access point's antenna port count and connector type before ordering.

Q: Does the antenna need power?
A: No. It is a passive antenna and requires no power.

Q: Is it suitable for outdoor installation?
A: Yes. It has an IP67 environmental rating and operates from -40 to 55 C, so it suits outdoor pole or wall mounting.

Q: What coverage pattern does it provide?
A: It is a directional patch antenna with 8 dBi peak gain on both bands, a 120 degree azimuth beamwidth and a 30 degree elevation beamwidth, which suits focused coverage of a defined area.

Q: How many connectors does it have and what type are they?
A: It has three N-Female bulkhead connectors, matching access points that use three external N-type antenna ports.
