Cisco ACC-LA-G-SM-SF | IR1800 Lightning Arrestor, SMA(m) to SMA(f), GDT

ACC-LA-G-SM-SF

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Lightning Arrestor is an inline gas discharge tube (GDT) surge protector for the antenna ports of Cisco Catalyst IR1800 Rugged Series routers. It is aimed at outdoor and remote deployments with externally mounted cellular or GNSS antennas, such as oil and gas sites, solar and wind farms and EV charging, where lightning-induced surges on the antenna cable are a risk to the router.

It is a straight SMA male to SMA female unit covering DC to 6 GHz, which spans cellular, Wi-Fi and GNSS bands. Because it passes DC, it can be used with active GNSS antennas that are powered through the cable. The gas tube design is a passive protection element, so no power, licence or subscription is needed.

Cisco lists this arrestor as an option for the SMA antenna ports of the IR1800 series. Other arrestors in the same Cisco lists use N-type or TNC connectors, or are high-pass filter types that do not pass DC and do not support GNSS, so this SMA GDT version is the one to choose when DC pass is required.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Gas-tube surge protection for the antenna line
- DC pass-through allows active GNSS antennas to be powered through the arrestor
- Wideband coverage from DC to 6 GHz, covering cellular, Wi-Fi and GNSS bands
- Straight SMA male to SMA female connection for inline installation
- Passive design with no power, licence or subscription required
- Listed by Cisco as a lightning arrestor option for IR1800 series routers

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Cisco PID: ACC-LA-G-SM-SF
- Product type: Lightning arrestor
- Connectors: SMA(m) to SMA(f)
- Connector orientation: Straight
- Arrestor type: Gas discharge tube (GDT)
- Frequency range: DC to 6 GHz
- DC pass: Yes
- Active GNSS antenna support: Yes
- Power: Passive, no power required

FAQs

Q: Does it need a licence or power?
A: No. It is a passive accessory, so no licence, subscription or power supply is required.

Q: Can I use it with an active GNSS antenna?
A: Yes. This gas discharge tube arrestor passes DC, so an active GNSS antenna can be powered through it.

Q: Which Cisco routers does it work with?
A: It is listed by Cisco as a lightning arrestor for the SMA antenna ports of Cisco Catalyst IR1800 Rugged Series routers.

Q: How does it differ from the N-type, TNC and high-pass filter arrestors?
A: This unit uses SMA(m) to SMA(f) connectors and a gas discharge tube. N-type and TNC arrestors use different connectors, and the high-pass filter types do not pass DC or support GNSS.
