• Cisco A9K-MPA-2X100G-FC black circuit board with silver connectors
1 1

Cisco

Cisco A9K-MPA-2X100G-FC | ASR 9000 2-Port 100GE Modular Port Adapter, FC

A9K-MPA-2X100G-FC

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This two-port 100 Gigabit Ethernet modular port adapter is designed for Cisco ASR 9000 Series modular line cards and delivers high-capacity 100G connectivity in a single bay. It is the Flexible Consumption Model (FC) variant, with port density, speed and optics selected per slot. It suits service provider and large enterprise aggregation and core deployments that need scalable 100G expansion on ASR 9000 400G and 200G modular line cards.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Plugs into the open bays of ASR 9000 400G and 200G modular line cards, so port density, speed and optics can be chosen per slot
- Supports LAN/WAN/OTN mode with two CFP2 coherent transceiver cages at 100 Gbps
- MACsec Layer 2 encryption support (IEEE 802.1AE) on 400G and 200G modular line cards, subject to minimum IOS XR software
- IEEE 802.3 compliant, with PHY monitoring and IEEE 802.x flow control

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 2 x 100 Gigabit Ethernet ports
- Requires CFP2 or CPAK optics
- Compatible optics include CFP2-ER4, CPAK-100G-LR4, CPAK-10x10LR, CPAK-100G-SR10, CPAK-100G-ER4L and CPAK-100G-CWDM4
- Minimum software: Cisco IOS XR 6.0.1
- Supported in bay 0 and bay 1 of the 400G modular line cards, and in bay 0 only of the 200G modular line cards
- Dimensions: 6.37 W x 1.36 H x 6.70 L in (8.30 in L including jackscrew)
- Weight: 38.4 oz (1.09 kg)
- Storage temperature: -40 to 70°C; operating humidity 10-85%

FAQs

Q: Which line cards does this port adapter fit?
A: It installs in the modular bays of Cisco ASR 9000 Series modular line cards. It is supported in bay 0 and bay 1 of the 400G modular line cards, and in bay 0 only of the 200G modular line cards.

Q: What optics does the A9K-MPA-2X100G-FC use?
A: It requires CFP2 or CPAK optics. Compatible options include CFP2-ER4, CPAK-100G-LR4, CPAK-10x10LR, CPAK-100G-SR10, CPAK-100G-ER4L and CPAK-100G-CWDM4.

Q: What software version is required?
A: A minimum of Cisco IOS XR 6.0.1 is required. MACsec support is subject to the minimum IOS XR software for the line card in use.

Q: Does this adapter support MACsec encryption?
A: Yes, MACsec Layer 2 encryption (IEEE 802.1AE) is supported on the 400G and 200G modular line cards, subject to the minimum IOS XR software.

Q: What does the FC suffix mean?
A: The FC suffix denotes the Flexible Consumption Model variant of the 2-port 100GE modular port adapter, which distinguishes it from the standard A9K-MPA-2X100GE SKU.
