• Cisco A9K-DC-PEM-V3 DC PEM V3 in 1U rackmount chassis with 5.25-inch bay
1 1

Cisco

Cisco A9K-DC-PEM-V3 | ASR 9000 DC Power Entry Module V3, Dual-Feed, 4.4kW

A9K-DC-PEM-V3

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The A9K-DC-PEM-V3 is a Version 3 DC power entry module for the Cisco ASR 9000 Series chassis. It houses the 4.4 kW DC power modules and provides dual-feed A/B input with hot-swap operation, making it suited to carrier and service provider sites running -48 VDC or -60 VDC plant power. The modular power architecture supports N+1 power module redundancy with no power zone or placement restrictions.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable, field-serviceable power entry module
- Dual-feed (A/B) DC input with feed redundancy
- Modular power architecture with no power zones or placement restrictions
- N+1 DC power module redundancy
- Houses the 4.4 kW Version 3 DC power modules

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Version 3 DC power system with 4400 W output per power module
- 4730 W total DC input per module
- Rated input voltage: -48 VDC nominal (North America), -60 VDC nominal (EU)
- Input voltage range: -40.5 to -72 VDC
- Rated input current: 49 A max at -48 VDC, 39 A max at -60 VDC
- N+1 DC power module redundancy
- A/B feed redundancy and PEM redundancy supported
- Operating temperature (nominal): 5 to 40 C
- Storage temperature: -40 to 70 C
- Operating humidity (nominal): 5 to 90% RH
- Compatible with ASR 9006, ASR 9010, ASR 9906, ASR 9910 and ASR 9912 chassis
- NEBS Level 3 (SR-3580) compliant chassis environment
- Supported from IOS XR Release 6.1.2

FAQs

Q: Which ASR 9000 chassis is the A9K-DC-PEM-V3 compatible with?
A: It is compatible with the ASR 9006, ASR 9010, ASR 9906, ASR 9910 and ASR 9912 chassis.

Q: Can I mix AC and DC power modules in the same chassis?
A: No. Mixing of AC and DC power modules is not supported, so a chassis fitted with this DC PEM should use DC power modules throughout.

Q: What DC input voltage does this PEM support?
A: The rated input is -48 VDC nominal (North America) or -60 VDC nominal (EU), with an operating range of -40.5 to -72 VDC.

Q: Does it support redundant power feeds?
A: Yes. It provides dual-feed A/B input with feed redundancy, and the DC power modules operate in N+1 redundancy.

Q: What IOS XR release is required?
A: The Version 3 power system is supported from IOS XR Release 6.1.2.
