Cisco A900-IMA4OS | ASR 900 4-Port OC3/STM-1 or 1-Port OC12/STM-4 Module

A900-IMA4OS

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This interface module for the Cisco ASR 900 Series aggregation routers provides TDM connectivity over SONET/SDH, offering either four OC-3/STM-1 ports or one OC-12/STM-4 port using pluggable SFP optics. It is suited to converged mobile, residential and business service deployments, including circuit emulation. The module supports 1+1 SONET APS and SDH Linear MSP for link protection, and is compatible with the A900-RSP2A-128 and A900-RSP2A-64 route switch processors.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- OIR field-replaceable SFP optics modules
- 1+1 SONET Automatic Protection Switching (APS) support
- SDH Linear Multiplex Section Protection (MSP) support
- Single interface module software reset
- Rolling software upgrade, interface module by interface module
- Supports converged mobile, residential and business services, including circuit emulation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Interface: 4-port OC3/STM-1 or 1-port OC12/STM-4 TDM
- Optics: pluggable SFP
- Power draw: 30W maximum
- Operating temperature: -40 to 65°C (-40 to 149°F) with industrial temperature SFP optics
- Storage temperature: -40 to 70°C, altitude 4570 m
- Relative humidity: 5 to 95%, noncondensing
- MTBF at 40°C: 1,493,730 hours
- Module shipment weight: 2.1 lbs
- Shipment package size (LxWxH): 15.44 x 9.44 x 4.31 inches
- Supported on A900-RSP2A-128 (all slots) and A900-RSP2A-64 (slots 0-2)
- Minimum software: IOS XE 3.12.0S on RSP1 (RSP1A-55/RSP1B-55); 3.14.0S on RSP2A

FAQs

Q: Which Cisco routers is the A900-IMA4OS designed for?
A: It is an interface module for the Cisco ASR 900 Series aggregation routers, including the ASR 902 and ASR 903.

Q: Which route switch processors support this module?
A: It is supported on the A900-RSP2A-128 in all slots and on the A900-RSP2A-64 in slots 0 to 2.

Q: Does the module include optics?
A: No. The module uses pluggable SFP optics, which are fitted to the ports according to the required OC-3/STM-1 or OC-12/STM-4 link.

Q: Can I operate it in extreme temperatures?
A: Yes. Operation from -40 to 65°C is supported when industrial temperature SFP optics are used.

Q: Does it support link protection?
A: Yes. It supports 1+1 SONET Automatic Protection Switching (APS) and SDH Linear Multiplex Section Protection (MSP).
