Cisco 84-MPA-2FH/6H-M | 8404 MPA, 2x400G QSFP56-DD + 6x100G QSFP28
SKU:84-MPA-2FH/6H-M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The 84-MPA-2FH/6H-M is a modular port adapter for the Cisco 8404 centralised router chassis in the Cisco 8000 Series. It suits service provider and data centre core, aggregation and edge deployments that need high-density 400G and 100G interfaces together with MACsec and precision timing in a compact 4RU router.
The adapter provides two 400G QSFP56-DD ports and six 100G QSFP28 ports, with up to 800 Gbps of throughput. The 400G ports support 4x100G breakout. It can run as 2x 400G in native mode, or as a mix of 400G and 100G where each group of three adjacent ports shares a total of 400G capacity. MACsec is supported on all ports and the module offers Class C timing. The adapter is a hot-swappable modular design that runs under Cisco IOS XR with the Cisco Silicon One K100 NPU in the host chassis.
The MPA itself has no separate licence, but the 8404 platform runs Cisco IOS XR under the Flexible Consumption Model 2.0, so port-speed Right-to-Use licences and term-based software licences are ordered separately. It is used with the Cisco 8404 centralised chassis (8404-SYS-D) and 8404-RSP1-48-EM route switch processors, and needs 400G QSFP56-DD and 100G QSFP28 optics.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- High-density 400G and 100G interface diversity for the Cisco 8404 centralised router
- MACsec encryption support on all ports
- Class C timing support
- Flexible 400G and 100G port operation with 4x100G breakout on the 400G ports
- Hot-swappable modular design within the 8404 chassis
- Runs under Cisco IOS XR with the Cisco Silicon One K100 NPU in the host chassis
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: 84-MPA-2FH/6H-M
- Description: Cisco 8404 MPA with 2x400G / 6x100G QSFP56-DD
- Product type: Modular port adapter for the Cisco 8404 router
- 400G ports: 2x QSFP56-DD
- 100G ports: 6x QSFP28
- Bandwidth: 800 Gbps
- MACsec: Yes, all ports
- Timing: Class C
- Breakout: 4x100G via the 400G ports
- Operating modes: 2x 400G native mode, or a mix of 400G and 100G with each of the three adjacent ports sharing a total of 400G capacity
- Weight: 3.08 lb (1.4 kg)
- Dimensions (H x W x D): 1.458 x 7.244 x 11.52 in. (37.05 x 18.40 x 29.28 cm)
- Host chassis operating temperature: -20 to 65 C (startup -5 C)
- Host chassis storage temperature: -40 to 85 C
- Host chassis humidity: 5% to 95% non-condensing
- Host chassis altitude: 0 to 3000 m
FAQs
Q: Does this port adapter need its own licence?
A: The MPA hardware has no separate licence. The Cisco 8404 platform runs Cisco IOS XR under the Flexible Consumption Model 2.0, so port-speed Right-to-Use licences (100G or 400G) and term-based software licences are ordered separately.
Q: Which chassis does the 84-MPA-2FH/6H-M work with?
A: It is designed for the Cisco 8404 centralised chassis (8404-SYS-D) with 8404-RSP1-48-EM route switch processors. The 8404 accepts two MPAs, and the other supported option is the 84-MPA-2H12Z-M.
Q: What optics does it use?
A: The two 400G ports take QSFP56-DD optics and the six 100G ports take QSFP28 optics. The 400G ports also support 4x100G breakout.
Q: Can the 400G and 100G ports all run at full rate at once?
A: The adapter runs in 2x 400G native mode, or in a mix of 400G and 100G where each group of three adjacent ports shares a total of 400G capacity. Maximum throughput is 800 Gbps.
Q: How is it powered?
A: It is powered from the Cisco 8404 chassis, which uses 1+1 redundant DC power entry modules (-40 to -72 VDC). The adapter has no separate power connection.
