• Cisco 5G-ANTM-GD black rectangular GPS antenna with metallic screw base
1 1

Cisco

Cisco 5G-ANTM-GD | 5G-ANTM Ground Disc for 5G/4G LTE Outdoor Antennas

5G-ANTM-GD

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The 5G-ANTM-GD is a passive metal ground disc that acts as a ground plane for Cisco 5G Sub-6GHz and 4G LTE multi-element outdoor and transportation antennas, including the 5G-ANTM-O-4-B. It suits ceiling-mount and non-metallic-surface installations where the antenna has no grounded metal surface beneath it.

The disc is a simple hardware accessory with no power draw and no licensing requirement. The antenna cables and mounting stud pass through the disc, and the slotted lock-nut is tightened beneath the mounting surface and the disc to hold everything in place.

It is used with Cisco industrial routers and industrial wireless access points that deploy these antennas, for example the IR1800 family. The disc is ordered separately from the antenna.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Provides a ground plane for the 5G-ANTM-O-4-B antenna on non-metallic mounting surfaces
- Suited to ceiling-mount installations of the 5G-ANTM-O-4-B antenna
- Antenna cables and mounting stud pass through the disc
- Slotted lock-nut tightens beneath the mounting surface and disc
- Passive hardware with no power or licensing needed
- Supports transportation and indoor antenna deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: 5G-ANTM-GD
- Accessory type: ground disc / ground plane
- Designed for: 5G Sub-6GHz and 4G LTE outdoor antennas
- Primary antenna match: 5G-ANTM-O-4-B
- Required for ceiling mount of the 5G-ANTM-O-4-B antenna
- Power: none, passive accessory
- Licensing: none

FAQs

Q: Which antenna does this ground disc work with?
A: It is designed for the Cisco 5G-ANTM-O-4-B multi-element LTE, Wi-Fi and GNSS antenna and is used with Cisco industrial routers and access points that deploy it, such as the IR1800.

Q: When is the ground disc required?
A: It is required when the 5G-ANTM-O-4-B antenna is ceiling mounted, and it is needed on non-metallic surfaces where there is no grounded metal to act as a ground plane.

Q: Does it need power or a licence?
A: No. It is a passive metal accessory with no power draw and no licensing requirement.

Q: How is it fitted?
A: The antenna cables and mounting stud pass through the disc, and the slotted lock-nut is tightened beneath the mounting surface and the disc.
