Cisco

Cisco 4G-LTE-ANTM-O-3-C | Dual LTE and GPS Outdoor Antenna, Blue, 4 ft SMA

4G-LTE-ANTM-O-3-C

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 3-in-1 multiband antenna houses two 4G LTE antennas and one active GPS antenna in a single low-profile radome. It is built for branch and remote-site routers that need cellular WAN connectivity with location data, indoors or outdoors. This SKU is the blue radome version with a 4 ft cable.

The LTE elements cover 698-960 MHz and 1710-2700 MHz with a typical gain of 2.5 dBi, 50 ohm impedance and a VSWR below 2.5:1. The GPS element operates on the L1 band at 1575.42 MHz with a 26 dBc amplifier gain and a 1.8 dB typical noise figure. The antenna is IP67 rated with a UV-resistant radome and an operating range of -40 to +85 C. The 4 ft RG174 cable terminates in SMA-male connectors. The LTE elements are passive, while the active GPS element is powered from the router's GPS port at 3.3-5 V DC.

It connects to the antenna ports of Cisco 819 series 4G LTE ISRs and Cisco EHWIC 4G LTE cards, and is also listed as a supported antenna for the Cisco 4G LTE 2.0 NIM. It can mount directly on a router, or on a grounded metal surface using optional extension cables for flush indoor or outdoor installations.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- No-tune multiband coverage with dual 4G LTE and GPS L1 frequencies
- Metal 5/8-inch stud mount with serrated face nut and a single cable exit for easier installation or replacement
- Optional peel-off adhesive backing for flat smooth surfaces
- Low-profile housing for added overhead clearance
- IP67-compliant design protects against water and dust in severe environments
- High-performance, low-loss cable and high-quality connectors for RF system efficiency
- UV-resistant blue radome

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Configuration: 3-in-1, 2 x 4G LTE + 1 x GPS (L1)
- LTE operating frequencies: 698-960 MHz, 1710-2700 MHz
- Typical LTE gain: 2.5 dBi
- Polarization: Vertical, linear
- Nominal impedance: 50 ohms
- Maximum power: 3 W
- VSWR: < 2.5:1
- Elevation plane (3 dB beamwidth): 30 degrees nominal
- Azimuth plane: Omni-directional
- Connector: SMA-male
- Cable: 4 ft RG174, VW-1 compliant
- Height: 90 mm
- Base diameter: 137 mm
- Colour: Blue radome
- Flammability rating: UL-94 V0
- Environment: Indoor and outdoor
- Ingress protection: IP67 (when mounted per installation instructions)
- Operating and storage temperature: -40 to +85 C
- GPS frequency band: 1575.42 MHz (GPS L1)
- GPS amplifier gain: 26 dBc +/- 3 dB
- GPS output VSWR: 1.5:1 typical
- GPS DC voltage: 3.3-5 V
- GPS DC current: 20 mA nominal, < 30 mA from -40 to +85 C
- GPS noise figure: 1.8 dB typical
- GPS filtering: > 40 dB rejection at +/-50 MHz from centre frequency

FAQs

Q: Which Cisco devices is this antenna compatible with?
A: It connects to the antenna ports of Cisco 819 series 4G LTE ISRs and Cisco EHWIC 4G LTE cards. It is also listed as a supported antenna for the Cisco 4G LTE 2.0 NIM.

Q: Does the antenna need external power?
A: The LTE elements are passive and need no power. The active GPS element is powered by the router's GPS port at 3.3-5 V DC, drawing 20 mA nominal.

Q: Can I extend the cable run to the antenna?
A: Yes. Optional extension cables are available: 4G-CAB-LMR240-25, -50 and -75 (25, 50 and 75 ft) and 4G-CAB-ULL-20 and -50 (20 and 50 ft). This allows indoor or outdoor flush installations on a grounded metal surface.

Q: How do I mount it?
A: It uses a 5/8 inch lug with a serrated face nut through a 5/8 inch hole in the mounting surface. An optional adhesive backing is available for a flat smooth surface of at least 17 square inches.

Q: Is it suitable for outdoor installation?
A: Yes. It is IP67 rated when mounted per the installation instructions, has a UV-resistant radome, and operates from -40 to +85 C.

Q: How does this SKU differ from the other colour versions?
A: The antenna is offered with a red, blue, black or white radome. This SKU is the blue radome version with a 4 ft cable.
