Description

The ONS 15216 1RU front-access mechanical frame is a passive 19-inch rack mounting shelf for Cisco ONS 15216 optical add/drop multiplexer (OADM) and mux/demux units. It suits point-to-point and low-channel-count CWDM or DWDM deployments where a cost-effective, unpowered optical shelf is needed.

The frame occupies one rack unit and provides four module positions with front access. It measures 44.298 mm high and 482.6 mm wide, weighs 0.22679618 kg and has a depth of 10.018 mm. It requires no electrical power and needs no licence, as it is passive mechanical hardware. It is rated for operation from 0 to +70 C and storage from -40 to +85 C, with humidity tolerance of 5% to 95% noncondensing.

The frame houses ONS 15216 OADM and mux/demux modules. For example, the 8-channel CWDM mux/demux unit (15216-FLC-CWDM-8) takes up two of the four positions, so a single frame can hold two such units.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Fits a standard 19-inch rack in a single rack unit
- Four positions for ONS 15216 OADM and mux/demux units
- Front-access design for easy module installation and cabling
- Passive design with zero electrical power requirement
- Suited to cost-effective point-to-point, low-channel-count CWDM and DWDM deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Rack size: 1RU, standard 19-inch rack mount
- Module positions: 4, for ONS 15216 OADM and mux/demux units
- Access: Front access
- Power: Passive, no electrical power required
- Height: 44.298 mm (1.744 in)
- Width: 482.6 mm (19 in)
- Depth: 10.018 mm (0.394 in)
- Weight: 0.22679618 kg (0.5 lb)
- Operating temperature: 0 to +70 C (32 to 158 F)
- Storage temperature: -40 to +85 C (-40 to 185 F)
- Humidity: 5% to 95% noncondensing
- Safety compliance (family): GR-1089, UL60950/CSA 22.2 No. 60950-00, IEC 60950
- Environmental compliance (family): GR-63-CORE

FAQs

Q: Does this frame need power or a licence?
A: No. It is a passive mechanical frame with no electrical power requirement and no licensing.

Q: What can be installed in this frame?
A: It houses Cisco ONS 15216 OADM and mux/demux modules across its four front-access positions.

Q: How many modules fit in one frame?
A: The frame has four positions. Some units occupy more than one, for example the 8-channel CWDM mux/demux (15216-FLC-CWDM-8) takes two positions.

Q: How much rack space does it use?
A: It occupies 1RU in a standard 19-inch rack.

Q: What temperature range is it rated for?
A: It operates from 0 to +70 C and can be stored from -40 to +85 C.
