Aruba S1F79A | AP-ANT-311 Tri-Band 1x1 Omni Dipole, RP-SMA Antenna
SKU:S1F79A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The AP-ANT-311 is an articulating, direct-mount, omni-directional dipole antenna for indoor Aruba access points. It covers the 2.4, 5 and 6 GHz bands, making it suited to Wi-Fi 6E and Wi-Fi 7 access points that need an omnidirectional coverage pattern for WLAN service delivery or air monitoring.
This is a 1x1 antenna with an RP-SMA connector that attaches directly to the access point. Gain is 3.0 dBi in the 2.4 GHz band and 6.0 dBi in both the 5 GHz and 6 GHz bands, with a 50 ohm impedance. It is a passive antenna, so it needs no power. This is the standard-profile version; the AP-ANT-312 is the low-profile alternative.
It is listed as an antenna option in the Aruba 500, 510, 530, 630 and 730 Series Campus Access Point QuickSpecs, and in the AP-760 installation guide.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Tri-band coverage across 2.4, 5 and 6 GHz for Wi-Fi 6E and Wi-Fi 7 access points
- Omni-directional pattern for WLAN service delivery or air monitoring
- Articulating direct-mount design
- RP-SMA connector attaches directly to the access point
- Passive design with no power requirement
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Antenna type: Tri-band 1x1 omni-directional dipole, articulating
- Frequency bands: 2.4 GHz / 5 GHz / 6 GHz
- Connector: RP-SMA plug, direct-mount
- Gain 2.4 GHz: 3.0 dBi
- Gain 5 GHz: 6.0 dBi
- Gain 6 GHz: 6.0 dBi
- Impedance: 50 ohm
- Environment: Indoor
- Power: Passive, no power required
FAQs
Q: Which Aruba access points is this antenna listed for?
A: It is listed as an antenna option for the Aruba 500, 510, 530, 630 and 730 Series Campus Access Points, and in the AP-760 installation guide.
Q: Does this antenna need power?
A: No. It is a passive antenna and draws no power.
Q: How does it differ from the AP-ANT-312?
A: The AP-ANT-311 is the standard-profile direct-mount antenna, while the AP-ANT-312 (S1F80A) is the low-profile version.
Q: Can it be used outdoors?
A: No. The AP-ANT-311 is designed for indoor use only.
