• Pale blue glossy ceramic square tile for Aruba S0A65A outdoor panel antenna
1 1

Aruba

Aruba S0A65A | ANT-4x4-D707 Dual-Band 7dBi 60x60deg Outdoor Antenna

S0A65A

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This dual-band 2.4/5 GHz outdoor panel antenna provides 4x4 MIMO with four elements, 7 dBi gain and 60 degree by 60 degree beamwidths. Its V/H/+/-45 multipolarised design suits sector coverage in outdoor wireless deployments, and four N-type female connectors allow it to be paired with connectorised outdoor access points such as the Aruba 570 Series. Wall or pole mounting makes it practical for campus, yard and site-wide coverage.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Multipolarised antenna for sector coverage on both 2.4 GHz and 5 GHz bands
- Four-element 4x4 MIMO design
- N-type female connectorised for external outdoor access points
- Suited to the Aruba 570 Series outdoor access points
- Wall or pole mounting for flexible outdoor installation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Dual-band 2.4/5 GHz
- 4x4 MIMO (4 elements)
- Nominal beamwidth 60 degrees horizontal x 60 degrees vertical
- Gain 7 dBi
- Polarisation V/H/+/-45
- Connectors 4 x N-type female
- Outdoor use, wall or pole mounting
- Impedance 50 ohm, VSWR 2:1
- Dimensions approx. 191 x 191 x 30 mm
- Weight approx. 997.9 g
- Operating temperature -45 to 70 C

FAQs

Q: Which access points is this antenna designed for?
A: It is an antenna option for the Aruba 570 Series outdoor access points, which use external connectorised antennas.

Q: What connectors does this antenna use?
A: It has four N-type female connectors, one for each element of the 4x4 MIMO design.

Q: Is it dual-band?
A: Yes. It covers both the 2.4 GHz and 5 GHz bands with a nominal 60 degree by 60 degree beamwidth and 7 dBi gain.

Q: How is the antenna mounted?
A: It is an outdoor panel antenna intended for wall or pole mounting.

Q: What polarisation does it support?
A: It is multipolarised, supporting vertical, horizontal and +/-45 degree polarisation.
