Aruba R6F26A | 200G QSFP56 to 2x100G QSFP56 AOC, 15m, MMF 850nm
SKU:R6F26A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Aruba R6F26A is a 15m active optical breakout cable with a 200G QSFP56 connector on one end and two 100G QSFP56 connectors on the other. It is built for data centre links where a single 200G port needs to feed two 100G devices, such as server or storage connections back to a switch, or switch-to-switch runs within a rack row.
The cable uses multimode fibre at 850nm with integrated optical transceivers, so no separate optics are needed. One 200G QSFP56 port is split into 2 x 100G links over a 15m reach. It is a server and storage class part in the HPE transceiver guide.
On Aruba switches, the transceiver guide lists it as supported on Aruba 9300 32D models running AOS-CX 10.15 or later, in ports 1-32. It is not supported on the Aruba 6300, 6400 and 8400 switch series.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Breakout from a single 200G QSFP56 port to two 100G links
- Active optical cable with integrated transceivers, so no separate optics are needed
- Multimode fibre at 850nm for in-rack and row-length runs up to 15m
- Suited to server and storage to switch connections
- Listed in the HPE Aruba Networking AOS-S and AOS-CX Transceiver Guide
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Cable type: Active Optical Cable (AOC)
- Breakout: 200G QSFP56 to 2 x 100G QSFP56
- Cable length: 15m
- Fibre type: Multimode, 850nm
- Connectors: QSFP56 (200G end) to 2 x QSFP56 (100G ends)
- Product class: Server/Storage
- Minimum software on Aruba 9300 32D: AOS-CX 10.15
- Aruba 9300 32D port support: ports 1-32
- Not supported on: Aruba 6300, 6400 and 8400 switch series
FAQs
Q: Which Aruba switches support the R6F26A?
A: The HPE transceiver guide lists it as supported on Aruba 9300 32D models from AOS-CX 10.15, in ports 1-32. It is not supported on the Aruba 6300, 6400 and 8400 series.
Q: What does this cable connect?
A: It connects one 200G QSFP56 port to two 100G QSFP56 ports, splitting a single 200G link into two 100G links over a 15m active optical cable.
Q: Do I need separate transceivers?
A: No. As an active optical cable, the optical transceivers are built into the cable ends, so no additional optics are required.
Q: What fibre type and reach does it use?
A: It uses multimode fibre at 850nm, with a fixed cable length of 15m.
