Aruba

Aruba R4D58A | MPO-16→8x LC duplex OM4 MMF breakout, 15m | Optics: 400GBASE-SR8 to 8x50GBASE-SR, 850nm, OM4 reach ≤100m; Connectors: MPO-16, LC duplex

SKU:R4D58A

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

High‑density OM4 multimode breakout harness for splitting one MPO‑16 SR8 port into eight LC duplex links. Ideal for 400G SR8 to 8×50G SR breakouts or migration to leaf/spine edge ports. Factory terminated, low‑loss ferrules, bend‑insensitive 50/125 µm fiber, and aqua jacket for easy identification. Length: 15 m. Standards compliant (TIA‑568.3‑D, IEC 61754‑7).

Features

- Optimized for 400G SR8 to multi‑link LC breakouts
- Low‑loss, factory‑tested terminations for minimized insertion loss
- Bend‑insensitive OM4 for tighter routing and improved handling
- Standards‑compliant construction for multi‑vendor interoperability
- Aqua jacket for clear multimode identification

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Will this cable work for breaking out a 400G SR8 port to multiple LC endpoints?
A: Yes. It is designed for 400GBASE‑SR8 MPO‑16 ports to break out into eight LC duplex SR links (e.g., 8×50G SR), subject to transceiver compatibility.

Q: Can I use this with patch panels or cassettes?
A: Yes. The MPO‑16 end connects to devices or modules that accept MPO‑16; the LC duplex ends connect to standard LC ports or panels.

Q: What polarity does this harness use?
A: It uses a standard SR8‑to‑LC breakout mapping suitable for SR8 to individual SR links. Always confirm polarity requirements in your optics documentation.

Q: Does the length include the breakout legs?
A: Yes. The stated length refers to the overall end‑to‑end assembly length.

Q: How do I ensure MPO gender compatibility?
A: Match the MPO gender and keying to your transceiver or module. Consult the optics datasheet to verify whether a male or female MPO interface is required.

Technical Specifications

- Cable type: OM4 multimode (50/125 µm), bend‑insensitive
- Length: 15 m
- Connector A: MPO‑16 (MTP) interface
- Connector B: 8× LC duplex breakout
- Fiber count: 16 fibers total (8 duplex LC legs)
- Supported applications: 400GBASE‑SR8 → 8×50GBASE‑SR breakouts; compatible with SR optics at 850 nm
- Wavelength: 850 nm (SR/MMF)
- Typical OM4 reach: up to 100 m for SR8 (transceiver‑dependent)
- Jacket color: Aqua (OM4 identification)
- Compliance: TIA‑568.3‑D, IEC 61754‑7 (MPO), IEC 11801, RoHS
