• White square foam drainage mat for Aruba JW001A dual-band AP antenna
1 1

Aruba

Aruba JW001A | AP-ANT-13B Dual-Band Omni Antenna, Downtilt, Ceiling Mount

JW001A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The AP-ANT-13B is a small, discreet dual-band indoor omni-directional antenna for ceiling installation, part of the Aruba AP-ANT indoor antenna range. It is designed for Aruba access points with external RP-SMA antenna connectors and suits high-density indoor Wi-Fi such as conference rooms, dense cubicle areas and offices that need a low-profile ceiling antenna.

It covers both the 2.4-2.5 GHz and 4.9-5.9 GHz bands with an omni-directional pattern that includes a downtilt, giving a well-defined coverage area beneath the antenna. It is a single omni antenna with a 50 ohm impedance and an RP-SMA connector, connected to the access point through a pigtail. The housing is PVC and ABS and measures approximately 2.2 x 2.2 x 0.6 in.

The antenna is passive and needs no power. It is listed as an indoor external antenna for Aruba APs with RP-SMA antenna interfaces, including the AP-204, AP-314, AP-504 and AP-514, and mounts to a ceiling T-bar using the supplied clips.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Compact, discreet package that blends into office environments
- Dual-band coverage across 2.4 GHz and 5 GHz
- Downtilt omni pattern gives a well-defined coverage area
- Suited to high-density, high-capacity indoor deployments
- Suited to conference rooms and dense cubicle areas
- Ceiling T-bar mounting for simple installation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: AP-ANT-13B
- Antenna type: Indoor, MIMO, ceiling mount, single omni-directional antenna
- Frequency range: 2.4-2.5 GHz and 4.9-5.9 GHz
- Directivity: Omni-directional with downtilt
- Connector: RP-SMA (used with pigtails)
- Impedance: 50 ohm
- Dimensions (W x D x H): 2.2 x 2.2 x 0.6 in
- Material: PVC, ABS
- Mounting: Ceiling mountable, indoor, 15/16 in T-bar clips
- Power: Passive antenna, no power required

FAQs

Q: Which Aruba access points can use this antenna?
A: It is intended for Aruba APs with RP-SMA external antenna interfaces, including the AP-204, AP-314, AP-504 and AP-514.

Q: Does it need power?
A: No. It is a passive antenna and requires no power of its own.

Q: How does it connect to the access point?
A: It has an RP-SMA connector and connects to the access point through a pigtail.

Q: Is it suitable for outdoor use?
A: No. It is designed for indoor ceiling-mount installations.

Q: What coverage pattern does it provide?
A: It is omni-directional with a downtilt, giving a well-defined coverage area below the ceiling, suited to conference rooms and dense cubicle areas.
