• Silver Arista Sfp-10G-T-RP 10gbase-t sfp+ transceiver modules with blue handles and metallic RJ45 copper connectors
1 1

Arista

Arista SFP-10G-T-RP | 10GBASE-T SFP+ Transceiver, RJ45, 30m, 1.5W Low Power

SFP-10G-T-RP

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista SFP-10G-T-RP is a 10GBASE-T copper SFP+ transceiver with an RJ45 connector. It suits top-of-rack and short inter-rack links where 10GBASE-T copper equipment needs to connect to Arista SFP+ or SFP25 switch ports over Cat6a cabling.

The module reaches up to 30m over Cat6a and supports 10G, 1G and 100M BASE-T operation. This reduced power variant has the same performance as the SFP-10G-T but draws a maximum of 1.5W from the host port, compared with 2W for the standard module. That lower draw helps in high-density deployments where many copper modules share a switch. The case operating temperature range is 0 to 70 C.

The transceiver is supported in all Arista SFP+ and SFP25 ports unless otherwise specified, with a minimum EOS version of 4.32.1. It is hot swappable, so it can be fitted or replaced without powering down the switch.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Same performance as the SFP-10G-T with module power reduced to 1.5W
- Supported in all Arista SFP+ and SFP25 ports unless otherwise specified
- Supports 10G, 1G and 100M BASE-T copper operation
- Hot swappable for easy replacement and maximum uptime
- RJ45 connector for direct connection to Cat6a copper cabling

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- PHY type: 10GBASE-T (10G/1G/100M BASE-T copper)
- Form factor: SFP+
- Connector type: RJ-45
- Cable type: Cat6a
- Maximum reach: 30m
- Maximum power consumption: 1.5W
- Dimensions (H x W x D): 8.55 x 13.7 x 56.5 mm
- Operating case temperature: 0 to 70 C
- Storage temperature: -40 to 70 C
- Relative humidity: 5 to 95%
- Operating altitude: 0 to 10,000 ft
- Minimum EOS version: 4.32.1

FAQs

Q: How does this differ from the SFP-10G-T?
A: Performance is identical, but this reduced power module draws a maximum of 1.5W, compared with 2W for the SFP-10G-T.

Q: What cable and distance does it support?
A: It uses Cat6a cabling with an RJ45 connector and reaches up to 30m.

Q: Which Arista ports and software does it work with?
A: It is supported in all Arista SFP+ and SFP25 ports unless otherwise specified, and requires EOS 4.32.1 or later.

Q: Does it support speeds below 10G?
A: Yes. The module supports 10G, 1G and 100M BASE-T copper operation.

Q: Can it be swapped while the switch is running?
A: Yes. The module is hot swappable, so it can be inserted or removed without powering down the switch.
