• Silver-colored Arista SFP-10G-MRA-T SFP+ transceiver modules with blue handles and metallic connectors for multi-rate copper RJ-45 use
1 1

Arista

Arista SFP-10G-MRA-T | 10G SFP+ RJ45 Copper Transceiver, Multi-Rate, 30m

SFP-10G-MRA-T

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This is a hot-swappable 10G SFP+ copper transceiver with an RJ45 port, designed to connect SFP+ switch ports to structured copper cabling. It is a rate adapting (multi-rate) module, so it adapts the speed between the switch host interface and the copper link.

The module reaches 30m over Cat6a at 10GBASE-T, and 5GBASE-T and 2.5GBASE-T links run up to 100m over Cat 5e. It supports 10G, 1G and 100M BASE-T operation, giving flexibility of media and speed on a port-by-port basis. Maximum power consumption is 2 W, drawn from the host SFP+ port with no separate supply needed.

The module is SFP+ MSA compliant (SFF-8431, 8461 and 8472) and fits SFP+ ports on Arista platforms. It is supported on specific platforms only, so check Arista's Transceiver and Cable Guide for the supported platform list before ordering.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot swappable to maximise uptime and simplify serviceability
- Rate adapting operation between the copper media interface and the host interface
- Copper RJ45 option for 10GbE SFP+ ports
- Flexibility of media and interface choice on a port-by-port basis
- SFP form factor gives a small, low-power solution for 1GbE to 25GbE
- Supports 10G, 1G and 100M BASE-T operation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- PHY type: 10GBASE-MRA-T (10GBASE-T rate adapting transceiver)
- Connector type: RJ-45
- Cable type: Cat6a
- Max reach (10GBASE-T, Cat6a): 30m
- Max reach (5GBASE-T and 2.5GBASE-T, Cat 5e): 100m
- Supported media rates: 10G/1G/100M BASE-T
- Form factor: SFP+ (8.55 x 13.7 x 56.5 mm, H x W x D)
- Power consumption (max): 2 W
- Operating case temperature: 0 to 70 C
- Storage temperature: -40 to 70 C
- Relative humidity: 5 to 95%
- Operating altitude: 0-10,000 ft
- IEEE compliance: 802.3 IEEE Ethernet
- MSA compliance: SFP+ SFF-8431, 8461 and 8472
- EMC: FCC Part 15 Class A, ICES-003 Issue 7, EN 55032:2015, EN 55035:2017, EN 300 386 V2.1.1
- Safety: EN 62368-1:2014 + A11:2017, IEC 62368-1:2014

FAQs

Q: What cable does this transceiver need?
A: For 10GBASE-T it needs Cat6a copper cabling, with a reach of up to 30m. For 5GBASE-T and 2.5GBASE-T links, Cat 5e cabling reaches up to 100m.

Q: What speeds does it support?
A: It supports 10G, 1G and 100M BASE-T operation. As a rate adapting module, it adapts the speed between the copper link and the switch host interface.

Q: How much power does it draw?
A: Maximum power consumption is 2 W. It is powered from the host SFP+ port, so no separate power supply is required.

Q: Which switches does it work with?
A: It fits SFP+ ports on Arista platforms and is SFP+ MSA compliant. It is supported on specific platforms only, so check Arista's Transceiver and Cable Guide for the supported platform list.

Q: Can it be installed while the switch is running?
A: Yes. The module is hot swappable, so it can be inserted or removed without powering down the switch.
