• Arista DCS-7020SR-32C2-F silver server rack with 32x 10GbE SFP+ downlinks
1 1

Arista

Arista DCS-7020SR-32C2-F | 7020R 32-Port 10G SFP+ Switch, 2x 100G, Front-to-Rear

DCS-7020SR-32C2-F

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7020R Series DCS-7020SR-32C2-F is a 1RU deep-buffer data centre switch running Arista EOS with L2/L3 switching. It suits lossless 10Gb or 1Gb leaf roles in universal cloud networks, big data and HPC, media and entertainment post-processing, edge computing and high-performance IP storage fabrics.

It provides 32 x 1/10GbE SFP+ ports and 2 x 100GbE QSFP100 uplinks, which run at wire-speed 100G or break out to 10G, 25G or 40G modes. Forwarding is up to 1.04 Tbps and 300 Mpps, with latency as low as 3.8 usec and a 3GB dynamic deep packet buffer. The Virtual Output Queue architecture avoids head-of-line blocking and absorbs bursts. This SKU uses front-to-rear airflow with AC power supplies, and it is a non-PoE switch.

The SFP+ ports take 1GbE and 10GbE optics and DACs. Supported power supplies are PWR-400AC and PWR-400-DC, in a 1+1 hot-swap arrangement with N+1 redundant fans.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Virtual Output Queue (VOQ) architecture eliminates head-of-line blocking and absorbs bursts
- Wire-speed unicast and multicast forwarding
- Each SFP+ port supports both 1GbE and 10GbE modes
- QSFP100 ports run at wire-speed 100G or break out to 10G, 25G or 40G
- Hot-swappable redundant power supplies and N+1 redundant fans
- Front removable power supplies, plus PPS input and output ports for clock connections
- Arista EOS with FlexRoute engine and NetDB for in-service software updates and self-healing resiliency
- Tool-less rails with 2-post and 4-post mounting

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 32 x 1/10GbE SFP+, 2 x 100GbE QSFP100
- RJ45 ports: none
- Maximum 25GbE ports: 8
- Maximum 40GbE ports: 2
- Maximum 100GbE ports: 2
- Throughput: 1.04 Tbps
- Packet rate: up to 300 Mpps
- Latency: as low as 3.8 usec
- Packet buffer: 3GB dynamic
- MAC entries: up to 256K
- IPv4/IPv6 routes: up to 200K
- IPv4/IPv6 host routes: up to 80K
- ECMP / MLAG: 128-way ECMP / 64-port MLAG
- CPU and memory: multi-core x86 CPU, 8GB DRAM, 4GB flash (minimum)
- Power draw (typical / maximum): 160 W / 189 W
- Supported power supplies: PWR-400AC, PWR-400-DC
- AC input (PWR-400AC): 100-240 VAC, 4.5 A max, 50/60 Hz
- DC input (PWR-400-DC): 24 VDC / 16 A, 48 VDC / 11 A, 60 VDC / 9 A
- Dimensions (W x H x D): 48.3 x 4.4 x 34.7 cm
- Weight: 6.4 kg
- Operating temperature: 0 to 40 C
- Storage temperature: -25 to 70 C
- Operating altitude: 0 to 3,000 m
- Relative humidity: 5 to 90% non-condensing
- Airflow: front-to-rear, 1RU

FAQs

Q: Does this switch provide PoE?
A: No. The DCS-7020SR-32C2-F is a non-PoE data centre switch with SFP+ and QSFP100 ports only.

Q: Which power supplies does it support?
A: It supports PWR-400AC and PWR-400-DC in a 1+1 redundant hot-swap arrangement. The -F suffix indicates AC power with front-to-rear airflow.

Q: What can the QSFP100 uplink ports do?
A: They run at wire-speed 100G or break out to 10G, 25G or 40G modes.

Q: Do the SFP+ ports support 1G as well as 10G?
A: Yes. Each of the 32 SFP+ ports supports both 1GbE and 10GbE modes.

Q: What operating system does it run?
A: It runs Arista EOS with L2/L3 switching, including the FlexRoute engine and NetDB for in-service software updates.
