Arista CAB-O-2Q-200G-1M | 200G OSFP to 2x 100G QSFP Breakout DAC Cable, 1m

CAB-O-2Q-200G-1M

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 1 metre passive twinax copper breakout cable connects a 200G OSFP port (200GBASE-CR8) to two 100G QSFP ports (100GBASE-CR4). It suits short-reach switch-to-server and switch-to-switch links within a rack or between adjacent racks, offering a cost-effective alternative to optics where distances are short. The EEPROM on each connector is programmed to indicate signal format and maximum data rate, supporting compatibility with non-Arista equipment such as server NICs.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Breakout DAC to connect an OSFP or QSFP-DD port to 2 x 100G QSFP ports
- EEPROM on each connector programmed to indicate signal format and maximum data rate
- Cost-effective short-distance intra-rack and inter-rack connectivity
- Suitable for connecting Arista switches to non-Arista equipment such as server NICs

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 200GBASE-CR8 OSFP to 2 x 100GBASE-CR4 QSFP breakout
- Passive twinax copper
- Length: 1 metre
- Connectors: OSFP to 2 x QSFP (QSFP28)
- Wavelength: n/a (copper)
- Minimum EOS version: 4.23.0
- EEPROM indicates support up to 25G NRZ data rates for compatibility with legacy NICs
- OSFP port must run at 200G total bandwidth to use this breakout

FAQs

Q: What does this cable connect?
A: It connects a 200G OSFP port (200GBASE-CR8) on one end to two 100G QSFP ports (100GBASE-CR4) on the other end, using passive twinax copper.

Q: Is this an active or passive cable?
A: It is a passive twinax copper DAC with no active signal conditioning, intended for short-reach links of up to 1 metre.

Q: Can it connect to non-Arista equipment such as server NICs?
A: Yes. It is suitable for connecting Arista switches to non-Arista equipment such as server NICs. The EEPROM indicates support up to 25G NRZ data rates for compatibility with legacy NICs.

Q: What EOS version is required?
A: The minimum supported EOS version is 4.23.0.

Q: Are there any port configuration requirements?
A: Yes. The OSFP port must run at 200G total bandwidth in order to use this breakout cable.
