• Arista 200G QSFP-DD to 4x QSFP28 DAC breakout cable, 2.5m
1 1

Arista

Arista CAB-D-4Q-200G-2.5 | 200G QSFP-DD to 4x QSFP Breakout DAC Cable, 2.5m

CAB-D-4Q-200G-2.5

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This passive twinax copper breakout cable connects one 200G QSFP-DD port to four QSFP ports running at 50G each. It suits short-reach, in-rack or adjacent-rack connections in data centre top-of-rack deployments, where a QSFP-DD switch port needs to feed multiple lower-speed QSFP ports.

The cable is 2.5 m long and uses 200GBASE-CR8 on the QSFP-DD end, splitting into 4 x 50GBASE-CR2 on the QSFP ends. The QSFP-DD port must be configured for 200G using 8 x 25G NRZ electrical lanes. Being passive, it contains no active electronics and draws any power it needs from the host port.

The breakout design allows interoperability with legacy 100G QSFP and 25G SFP ports. It belongs to the Arista 400G QSFP-DD twinax copper breakout cable family, which is offered in 1 m, 2 m and 2.5 m lengths.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Breaks out one 200G QSFP-DD port into four QSFP ports
- Passive twinax copper construction with no active electronics
- Works with legacy QSFP ports through 8 x 25G NRZ lane mode on the QSFP-DD port
- Suited to short-reach in-rack and adjacent-rack data centre links
- Part of a family offered in 1 m, 2 m and 2.5 m lengths

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- PHY type: 200GBASE-CR8 to 4x 50GBASE-CR2
- Connector type: QSFP-DD to 4x QSFP
- Cable type: Twinax copper (passive)
- Length: 2.5 m
- Breakout configuration: 1x 200G QSFP-DD to 4x 50G QSFP
- Port configuration: QSFP-DD port set to 200G using 8 x 25G NRZ electrical lanes
- Power: Passive, no external power required
- Interoperability: Legacy 100G QSFP and 25G SFP ports
- Family lengths: 1 m, 2 m and 2.5 m

FAQs

Q: Does this cable need external power?
A: No. It is a passive twinax copper cable with no active electronics, so it draws any power it needs from the host port.

Q: What port configuration does the QSFP-DD end need?
A: The QSFP-DD port must be configured for 200G using 8 x 25G NRZ electrical lanes. This is what allows the breakout to the four QSFP ports.

Q: What can the four breakout ends connect to?
A: The far-end connectors are QSFP ends running at 50G each, and the design allows interoperability with legacy 100G QSFP and 25G SFP ports.

Q: What is the cable length and how does it differ from sibling SKUs?
A: This SKU is 2.5 m long. The same breakout cable family is also offered in 1 m and 2 m lengths.

Q: What is the maximum reach of this cable type?
A: Passive twinax copper is intended for short reach. For this QSFP-DD to 4x QSFP family the available lengths run up to 2.5 m.
