• Four colorful Arista QSFP-100G-CWDM4 USB flash drives
1 1

Arista

Arista QSFP-100G-CWDM4 | 100G QSFP28 Transceiver, CWDM4, 2km SMF, Duplex LC

QSFP-100G-CWDM4

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista QSFP-100G-CWDM4 is a hot-swappable 100GBASE-CWDM4 QSFP28 transceiver for 100G links over duplex single-mode fibre with LC connectors. It follows the 100G CWDM4 MSA and suits leaf-spine interconnects and inter-building links in data centre and campus networks where the run is 2 km or less. Because it uses duplex fibre, no parallel MPO cabling is needed, which makes it a lower-cost alternative to PSM4 or LR4 optics at this reach.

The module reaches up to 2 km over G.652 single-mode fibre using four CWDM wavelengths around 1271, 1291, 1311 and 1331 nm. It supports dual-rate 100G/40G operation, so the same optic can also run at 40G. Maximum power consumption is 3.5 W, drawn from the host switch QSFP port, and no licence or subscription is required.

It fits QSFP and QSFP28 100G ports on Arista switches and interoperates with other 100GBASE-CWDM4 MSA optics over duplex single-mode fibre with LC connectors. Refer to Arista's Transceiver and Cable Guide for the supported platform list.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable to maximise uptime and simplify serviceability
- Dual-rate 100G/40G operation
- Compliant with the 100G CWDM4 MSA
- Duplex single-mode fibre reach of up to 2 km without parallel MPO cabling
- QSFP form factor for high-density 100G deployments
- Optical interoperability with 100GbE CFP, CFP2 and CPAK form factors

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- PHY type: 100GBASE-CWDM4
- Form factor: QSFP (QSFP28)
- Data rate: 100G/40G dual rate
- Connector type: Duplex LC
- Cable type: SMF G.652
- Maximum reach: 2 km
- CWDM wavelengths: 1271 / 1291 / 1311 / 1331 nm
- Tx power: -6.5 to +2.5 dBm per lane
- Rx power: -11.5 to +2.5 dBm per lane
- Maximum power consumption: 3.5 W
- Dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- Operating case temperature: 0 to 70 C
- Storage temperature: -40 to 70 C
- Relative humidity: 5 to 95%
- Operating altitude: 0 to 10,000 ft
- MSA and standards: 100G CWDM4 MSA, SFF-8449, SFF-8636, IEEE 802.3
- Laser safety: Class 1 or 1M (IEC/EN 60825-1)
- Certifications: CE, KCC, Australia RCM, UKCA

FAQs

Q: Does this transceiver need a licence or subscription?
A: No. It is a passive optical module that needs no licence or subscription.

Q: What fibre and connector does it use?
A: It uses duplex G.652 single-mode fibre with LC connectors, so no parallel MPO cabling is required.

Q: Can it run at 40G as well as 100G?
A: Yes. It supports dual-rate 100G/40G operation, so it can also be used for 40G links.

Q: How much power does it draw?
A: Maximum power consumption is 3.5 W, supplied by the host switch QSFP port.

Q: What does it interoperate with?
A: It fits QSFP and QSFP28 100G ports on Arista switches and links with other 100GBASE-CWDM4 MSA optics over duplex single-mode fibre with LC connectors.
