HPE Q9D33A | SN6610C 16-Port 32G FC Expansion Module
SKU:Q9D33A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The SN6610C 16-port Fibre Channel expansion module is built for the HPE SN6610C fabric switch, based on the MDS 9132T. It fits the switch's expansion slot and adds 16 active 32Gbps ports. This lets a SAN grow from 16 active ports to 24 or the full 32, which suits all-flash array and virtualised workload SANs and edge-of-SAN switching in small, midsize and large enterprises.
The module provides 16 x 32Gbps Fibre Channel ports that autosense 8, 16 and 32 Gbps, each with dedicated 32 Gbps bandwidth. A fully populated SN6610C reaches thirty-two 32Gbps ports and up to 1024 Gbps of aggregate bandwidth. The 16 ports are active as shipped. It draws power from the host chassis, with a typical 43 W when idle with 16 ports activated and no SFPs installed. SFP+ optics are ordered separately. MDS 9000 NX-OS 8.2(1) or later is required.
It is for the SN6610C only, and it is the required expansion module for running more than 16 active ports. Supported optics are the genuine HPE C-series parts Q9D30A, Q9D31A, C8S72A, C8S73A, AJ906A and AJ907A.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Pay-as-you-grow port expansion, taking the SN6610C from 16 to 24 or 32 active ports
- Full non-blocking 32Gbps Fibre Channel performance on line-rate ports
- NPIV, NPV and F-port channeling for SAN scaling
- VSANs for fabric isolation and PortChannels for ISL resiliency
- Built-in analytics and telemetry from the next-generation ASIC platform
- Managed via CLI, REST/NX-API and Nexus Dashboard Fabric Controller (NDFC)
- FC-NVMe support
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: Q9D33A
- Host switch: HPE SN6610C (MDS 9132T)
- Active ports on module: 16 x 32Gbps Fibre Channel
- Port speed: 8, 16 and 32 Gbps autosensing, 32 Gbps dedicated bandwidth per port
- Maximum ports per SN6610C chassis: 32 x 32Gbps Fibre Channel
- Aggregate bandwidth (SN6610C chassis): up to 1024 Gbps
- Slots per host chassis: one fixed and one expansion slot
- Buffer credits: up to 8300 for a group of 16 ports, default 500 per port
- PortChannel: up to 16 ports in a PortChannel
- VSANs: up to 32 per switch
- Typical power consumption (idle module, 16 ports activated, no SFPs): 43 W
- Optics: SFP+ required, ordered separately
- Minimum software: MDS 9000 NX-OS 8.2(1)
FAQs
Q: Which switch is this expansion module for?
A: It is for the HPE SN6610C (MDS 9132T) only. It is the required expansion module for running more than 16 active ports on that switch.
Q: Does it need a separate licence to activate the ports?
A: No. The 16 ports on the module are active as shipped. Optional software subscriptions such as Advantage and Premier are available for the host switch.
Q: Which optics can be used with it?
A: SFP+ optics are ordered separately. Supported genuine HPE parts are Q9D30A and Q9D31A (32Gb), C8S72A and C8S73A (16Gb), and AJ906A and AJ907A (8Gb).
Q: Does the module need its own power supply?
A: No. It draws power from the host SN6610C chassis, typically 43 W when idle with 16 ports activated and no SFPs.
Q: What software version is required?
A: MDS 9000 NX-OS 8.2(1) or later is required.
