• HPE ProLiant DL380 Gen10 server rack with P84180-B25 46TB SSD array
1 1

HPE

HPE P84180-B25 | Dual-controller SFF array; 12Gb SAS host (4 ports/ctrl); 12x 3.84TB SSD ≈46TB raw; 24 SFF bays (12 populated); 2U; RAID 0/1/5/6/10

P84180-B25

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.

 Trade supply only. Server & GPU quote requests need a company name, ABN and work email address. We do not quote Gmail, Outlook or Hotmail addresses, or supply for home use.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Custom Built Servers

Need a different spec, quantity or configuration?

We build configured-to-order refurbished servers from Cisco, Dell, HPE, NVIDIA Lenovo and Supermicro. Tell us what you need and we'll come back with options within 24 hours.

Configure your server now →

Description

Enterprise SFF storage array with dual active/active controllers and 12Gb SAS host connectivity. Delivered with 12x 3.84TB SSDs (≈46TB raw) installed, leaving 12 open bays in the 2U, 24-bay chassis for future growth. Combines consistent low latency with thin provisioning, snapshots, and flexible RAID for mixed workloads. Ideal for direct-attached or SAS SAN designs using redundant HBAs and MPIO.

Features

- 12Gb SAS host connectivity with 8 total host ports
- 46TB raw SSD capacity for performance-intensive workloads
- Dual active/active controllers for resilience and scalability
- Thin provisioning and snapshots to optimize storage efficiency
- Redundant power and hot-swappable components
- Room to grow with 24 SFF bays (12 open)

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Series: MSA 2070 SFF
- Chassis: 2U rack-mount
- Drive bays: 24x 2.5" SFF (12 populated)
- Included drives: 12x 3.84TB SSD (≈46.1TB raw)
- Controllers: 2x active/active
- Host interface: 12Gb SAS
- Host ports: 4 per controller (8 total)
- RAID levels: 0, 1, 5, 6, 10
- Data services: thin provisioning, snapshots (replication optional/licensable)
- Power: dual hot-swappable PSUs
- Management: web GUI and CLI
- Use cases: virtualization, databases, file/block workloads

FAQs

Q: Can servers connect directly without a switch?
A: Yes. Hosts can connect directly via 12Gb SAS HBAs; use MPIO for redundancy.

Q: How much usable capacity will I get?
A: Usable capacity depends on RAID level, provisioning, and metadata overhead; ≈46TB is the raw total across 12x 3.84TB SSDs.

Q: Are additional drives supported later?
A: Yes. You can populate the remaining SFF bays and expand pools/volumes per best practices.

Q: Does it support snapshots and clones?
A: Yes, snapshots and volume copies are supported; some advanced features may require licenses.
