Cisco QDD-400G-SR4.2-BD | 400G QSFP-DD Transceiver, SR4.2, MPO-12, 100m OM4
SKU:QDD-400G-SR4.2-BD
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco QDD-400G-SR4.2-BD is a 400G QSFP-DD multimode transceiver for data centre, high-performance computing, enterprise core and distribution, and service provider networks. It carries 400GE over existing OM4 multimode MPO-12 cabling, and can also be used as a 4x100GE breakout to QSFP-100G-SR1.2 modules.
This 400GBASE-SR4.2 module uses four fibre pairs with two bidirectional SWDM wavelengths per fibre, at 850 nm and 908 nm, through an MPO-12 UPC connector. Reach is 70 m on OM3, 100 m on OM4 and 150 m on OM5. The host electrical interface is 400GAUI-8, and maximum power consumption is 12 W per module.
Because it is based on 2x50G bidirectional wavelengths per fibre, it is not interoperable with standard 400GBASE-SR8 or SR4 optics. It is supported on Cisco QSFP-DD switches and routers, with FEC performed on the host platform. QSFP-DD ports are backward compatible with QSFP+, QSFP28 and QSFP56 modules.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable QSFP-DD module
- 4x100GE breakout capability to QSFP-100G-SR1.2 modules
- Two bidirectional SWDM wavelengths per fibre across four fibre pairs
- Certified and tested on Cisco QSFP-DD 400G ports
- Compliant with IEEE 802.3bm, QSFP-DD MSA CMIS Rev4.1, OIF 56G PAM4 and 100G Lambda MSA
- QSFP-DD ports are backward compatible with QSFP+, QSFP28 and QSFP56 modules
- Interoperable with other IEEE-compliant 400GBASE interfaces where applicable
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Standard: 400GBASE-SR4.2 (SWDM BiDi)
- Form factor: QSFP-DD
- Optical connector: MPO-12 UPC
- Fibre type: multimode, 50 micron
- Reach: 70 m OM3 / 100 m OM4 / 150 m OM5
- Nominal wavelength: 850 nm and 908 nm
- Nominal data rate: 425 Gbps
- Electrical interface: 400GAUI-8 / CEI-56G-VSR-PAM4
- Average transmit power per lane: -6.2 dBm min, 4 dBm max
- Average receive power per lane: -8.2 dBm min, 4 dBm max
- Maximum supported insertion loss: 1.9 dB
- Pre-FEC BER: 2.4x10-4
- Maximum power consumption: 12 W
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight: 100 g maximum
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C
- Laser class: 1
- Pull tab colour: Gray
- Breakout: 4x100G to QSFP-100G-SR1.2
FAQs
Q: Does this transceiver need a licence or subscription?
A: No. The transceiver itself does not require a licence or subscription.
Q: Can it be used for 4x100G breakout?
A: Yes. It supports 4x100G breakout to QSFP-100G-SR1.2 modules, with 70 m reach on OM3, 100 m on OM4 and 150 m on OM5.
Q: Is it interoperable with 400GBASE-SR8 or SR4 optics?
A: No. It is based on 2x50G bidirectional wavelengths per fibre, so it is not interoperable with standard 400GBASE-SR8 or SR4 optics. Check the Cisco Module Interoperability Matrix before mixing it with other optics.
Q: What power does the module draw?
A: Maximum power consumption is 12 W per module, drawn from the host QSFP-DD port.
Q: What fibre and connector does it use?
A: It uses 50 micron multimode fibre with an MPO-12 UPC connector, reaching 100 m on OM4.
Q: Which Cisco platforms support it?
A: It is supported on Cisco QSFP-DD switches and routers listed in the Cisco Transceiver Modules Compatibility Matrix. FEC is performed on the host platform.
