Cisco PWR-C2-640WDC | Catalyst 3650 640W DC Power Supply, -48V, Config 2

SKU:PWR-C2-640WDC

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The PWR-C2-640WDC is a hot-swappable 640W DC power supply module for Cisco Catalyst 3650 switches. It is the only DC-input option in the Config 2 power supply range, which makes it the choice for DC-powered telecom, central-office and other -48 VDC environments that run Catalyst 3650 access switches. It can also be paired with a second supply where redundancy is wanted.

The module accepts dual input feeds (A and B) at -36 to -72 VDC, with -48 VDC nominal for domestic use and -60 VDC nominal internationally. Input current is 21 to 10.5 A. Maximum output is 640W, delivered as +12 V at 20.83 A and -54 V at 7.36 A. On a 48-port PoE Catalyst 3650, a single 640W supply provides up to 390W of PoE, and two supplies are needed for full PoE+ on the 24-port models.

It is supported in the Catalyst 3650-24TS, 24PS, 24TD and 24PD, and in the 3650-48TS, 48PS, 48FS, 48TD, 48PD, 48FD, 48FQ, 48PQ and 48TQ switches. Other power supplies for the same chassis include the PWR-C2-250WAC, PWR-C2-640WAC and PWR-C2-1025WAC.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swap, field-replaceable power supply module
- Dual DC input feeds (A and B)
- DC OK and PS OK status LEDs
- Terminal block with safety cover and grounding terminal
- Extraction handle and release latch
- Only DC power supply module available for the Catalyst 3650
- Can be paired with a second supply for redundancy or to raise the PoE budget

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Maximum output power: 640W
- DC input voltage: -36 to -72 VDC
- Domestic voltage range: -36 VDC min, -48 VDC nominal, -72 VDC max
- International voltage range: -36 VDC min, -60 VDC nominal, -72 VDC max
- Input current: 21 to 10.5 A
- Output ratings: +12 V at 20.83 A and -54 V at 7.36 A
- Output voltage range: 51 to 57 V
- Total input: 719 W, 2444 BTU/hr
- Total output: 640 W, 2188 BTU/hr
- Input feeds: Dual (A and B)
- Branch circuit protection: 25 A
- Ground wire gauge: 12 AWG or 8 AWG
- Dimensions (H x W x D): 4.0 x 9.5 x 29.8 cm (1.58 x 3.75 x 11.75 in.)
- Weight: 1.25 kg (2.75 lb)
- MTBF: 706,759 hours
- Operating temperature: -5 to +45 C up to 1800 m, -5 to +40 C up to 3000 m, -5 to +35 C up to 4000 m, -5 to +30 C up to 5000 m
- Altitude: up to 5,000 m (16,400 ft)
- Front-panel indicators: DC OK LED, PS OK LED

FAQs

Q: Does this power supply need a licence?
A: No. It is a hardware power module and does not require any licence or subscription.

Q: What DC input does it need?
A: It takes a -36 to -72 VDC input on dual A and B feeds, with -48 VDC nominal for domestic use and -60 VDC nominal internationally. Input current is 21 to 10.5 A, and a 25 A branch circuit protection requirement applies.

Q: Which switches is it compatible with?
A: It is supported in Catalyst 3650-24TS, 24PS, 24TD and 24PD, and in 3650-48TS, 48PS, 48FS, 48TD, 48PD, 48FD, 48FQ, 48PQ and 48TQ switches.

Q: How much PoE does it provide?
A: On a 48-port PoE Catalyst 3650, a single 640W supply provides up to 390W of PoE. Two 640W supplies are needed for full PoE+ on the 24-port models.

Q: Can it be used for power supply redundancy?
A: Yes. It can be paired with a second supply in the Config 2 range for redundancy or to raise the PoE budget. Other supported modules for the same chassis are the PWR-C2-250WAC, PWR-C2-640WAC and PWR-C2-1025WAC.
