Cisco PWR-C2-640WAC/2 | Catalyst 2960-XR 640W AC Secondary Power Supply
SKU:PWR-C2-640WAC/2
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The PWR-C2-640WAC/2 is a hot-swappable 640W AC Config 2 power supply module with an integrated fan, designed for Cisco Catalyst 2960-XR and Catalyst 3650 switches. The /2 designation marks it as the secondary power supply option, so it suits campus and branch access switching where you want added PoE+ capacity and power resiliency.
It delivers a maximum 640W output from a 100 to 240 VAC autoranging input at 50 to 60 Hz, drawing 8-4 A. Output rails are +12 V at 20.83 A and -54 V at 7.36 A. Input draw is about 695W (2371 BTU/hr) against 640W output (2183 BTU/hr), with BTU ratings based on 100 VAC. The module weighs 1.41 kg and measures 4.0 x 9.5 x 29.8 cm (H x W x D). No licence is required.
It is compatible with Catalyst 2960-XR PoE+ models such as WS-C2960XR-24PS-I, 24PD-I, 48LPS-I and 48LPD-I, as well as the Catalyst 3650 series. Installed as a redundant supply in supported 2960-XR PoE+ switches, it retains the 370W PoE+ budget if one supply fails. It is not supported in the 2960XR-48FPD-I and 2960XR-48FPS-I, which use PWR-C2-1025WAC.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable field-replaceable power supply with integrated cooling fan
- Provides redundancy when installed as a second power supply in supported 2960-XR PoE+ switches
- Autoranging AC input for worldwide use
- Supports a 370W PoE+ budget on supported Catalyst 2960-XR PoE models
- Usable as a secondary or spare FRU for Catalyst 3650 switches
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Maximum output power: 640 W
- Input voltage: 100 to 240 VAC autoranging
- Input frequency: 50 to 60 Hz
- Input current: 8-4 A
- Output current: +12 V @ 20.83 A, -54 V @ 7.36 A
- Total input: 2371 BTU/hr, 695 W
- Total output: 2183 BTU/hr, 640 W
- Form: hot-swappable FRU with integrated fan
- Weight: 1.41 kg (3.1 lb)
- Dimensions (H x W x D): 4.0 x 9.5 x 29.8 cm (1.58 x 3.75 x 11.75 in.)
- MTBF: 1,000,000 hours
- PoE+ capacity in 2960-XR with single or redundant supply: 370 W
FAQs
Q: Which switches is the PWR-C2-640WAC/2 compatible with?
A: It works with Catalyst 2960-XR PoE+ models such as WS-C2960XR-24PS-I, 24PD-I, 48LPS-I and 48LPD-I, and with the Catalyst 3650 series.
Q: Can I use it in the Catalyst 2960XR-48FPD-I or 48FPS-I?
A: No. Those two models only support the PWR-C2-1025WAC power supply.
Q: Does it need a licence?
A: No licence is required. It is a hardware power supply module.
Q: What AC input does it accept?
A: It accepts 100 to 240 VAC autoranging at 50 to 60 Hz with an 8-4 A input current, so it can be used with mains supplies worldwide.
Q: Is it hot-swappable?
A: Yes. It is a field-replaceable unit with an integrated fan, and when installed as a redundant supply it helps keep the switch powered if the other supply fails.
