Cisco

Cisco PWR-C2-250WAC/2 | Catalyst 250W AC Config 2 Power Supply, Spare

SKU:PWR-C2-250WAC/2

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 250W AC power supply is a hot-swappable field-replaceable unit with an integrated fan, built for Catalyst switches that use the Config 2 power supply bay. It suits access-layer Catalyst 2960-XR and Catalyst 3650 deployments, either as a spare, a replacement, or a second supply for power redundancy.

The module delivers 250W of output at +12V and 20.83A from an autoranging 100-240 VAC, 50-60 Hz input, drawing 4-2A. Total input power is 277W (945 BTU per hour). It carries AC OK and PS OK status LEDs, weighs 1.16 kg and measures 4.0 x 9.5 x 29.8 cm. This is the spare version of the Config 2 250W AC supply. It provides no PoE budget of its own and needs no licence.

In Catalyst 2960-XR switches it is the default supply on the non-PoE models such as the 2960XR-24TS-I, 48TS-I, 24TD-I and 48TD-I, and can be fitted as a second supply. The 3650 also uses it. It is not supported in the 2960XR-48FPD-I or 2960XR-48FPS-I, which require the PWR-C2-1025WAC.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable field-replaceable unit with built-in fan
- Autoranging AC input from 100 to 240 VAC
- Can act as a secondary supply to give power redundancy in supported switches
- AC OK and PS OK status LEDs for at-a-glance power monitoring
- Primary or secondary supply in non-PoE Catalyst 2960-XR switches
- Spare (=) version of the Config 2 250W AC supply

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Part description: 250W AC Config 2 Power Supply, Spare
- Maximum output power: 250 W
- Output rating: +12 V @ 20.83 A
- Input voltage and frequency: 100-240 VAC (autoranging), 50-60 Hz
- Input current: 4-2 A
- Total input power: 277 W, 945 BTU per hour
- Total output power: 250 W, 853 BTU per hour
- BTU ratings basis: 100 VAC
- Form factor: hot-swappable FRU with integrated fan
- Power supply bay: Config 2
- Indicators: AC OK LED, PS OK LED
- Dimensions (H x W x D): 4.0 x 9.5 x 29.8 cm (1.58 x 3.75 x 11.75 in.)
- Weight: 1.16 kg (2.55 lb)
- MTBF: 1,000,000 hours

FAQs

Q: Does this power supply need a licence?
A: No. It is a hardware power supply module and needs no licence or subscription.

Q: Which switches does it work with?
A: It fits Catalyst 2960-XR switches, where it is the default supply on the non-PoE models such as the 2960XR-24TS-I, 48TS-I, 24TD-I and 48TD-I. It is also used in Catalyst 3650 switches.

Q: Can I use it in the 2960XR-48FPD-I or 2960XR-48FPS-I?
A: No. Those two models only support the PWR-C2-1025WAC.

Q: Does it provide PoE power?
A: No. It delivers 250W at +12V for the switch itself and provides no PoE budget of its own.

Q: Can it be used for power redundancy?
A: Yes. In supported switches it can be fitted as a second supply, and it is hot-swappable, so a unit can be replaced without powering the switch down.

Q: How does it differ from the other Config 2 power supplies?
A: This is the 250W AC supply. The PWR-C2-640WAC and PWR-C2-1025WAC are higher-output Config 2 supplies for the same bay.
