Cisco PWR-C1-715WDC | Catalyst 9300 715W DC (-48V) Power Supply, Config 1
SKU:PWR-C1-715WDC
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a hot-swappable 715W DC power supply module for the Cisco Catalyst 9300 series. It suits campus and branch access or aggregation switching in sites with a -48 VDC power plant, such as telecom rooms, industrial sites and DC-powered wiring closets. It can be fitted as the primary or secondary supply to provide PoE budget and power redundancy.
The module accepts a nominal -48 VDC input across a -36 to -72 VDC range, with up to 24 A input current, and delivers -56 V at 12.8 A to the switch. Output holdup time is a minimum of 2 ms at -48 VDC. It is a Config 1 supply with a right-angle barrier-style terminal block for the positive, negative and grounding connections, protected by a safety cover. DC OK and PS OK LEDs show supply status, and a release latch with extraction handle makes replacement straightforward. It operates from -5 to +45 C up to 1500 m.
It is supported on Catalyst 9300, 9300L and 9300X series switches. It can be paired with PWR-C1-715WAC, PWR-C1-715WAC-P and PWR-C1-1100WAC supplies in the switch power-supply bays, and is also a 715W DC secondary option for C9300LM modular models.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable, field-replaceable module
- Supports power redundancy (N+1 or N+N depending on switch configuration)
- Terminal block with safety cover for DC wiring
- Release latch and extraction handle for easy replacement
- DC OK and PS OK status LEDs
- Interchangeable across Catalyst 9300, 9300L and 9300X series switch hardware
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Power supply rated maximum: 715W
- Input voltage range: -36 to -72 VDC
- Nominal input: -48 VDC
- Input current: 24-12 A
- Output ratings: -56 V at 12.8 A
- Output holdup time: 2 ms minimum at -48 VDC
- Total output heat: 2440 BTU/hr
- Input receptacle: Right-angle barrier-style terminal block
- Power cord rating: 25 A @ 100 VDC
- Dimensions (H x W x D): 1.58 x 3.25 x 12.20 in
- Weight: 2.2 lb (1 kg)
- MTBF: 1,812,103 hours (-48 V input at 40 C)
- Operating temperature: -5 to +45 C up to 1500 m; -5 to +40 C up to 3000 m
- Indicators: DC OK LED, PS OK LED
- Terminals: Positive input, negative input, grounding terminal with safety cover
- Power supply type: Config 1
FAQs
Q: Which switches does the PWR-C1-715WDC work with?
A: It is supported on Catalyst 9300, 9300L and 9300X series switches. It is also a 715W DC secondary power supply option for C9300LM modular models.
Q: What input power does it need?
A: It needs a nominal -48 VDC supply, with an accepted range of -36 to -72 VDC and up to 24 A input current. Wiring is made at the terminal block, which has a safety cover.
Q: Is one 715W DC supply enough for PoE?
A: On Catalyst 9300 PoE models, one PWR-C1-715WDC is sufficient for 24-port PoE at 15.4W per port. Higher PoE or PoE+ budgets on 48-port models need two 715W supplies, or a 715W supply paired with a 1100W supply.
Q: Can it be mixed with AC power supplies?
A: Yes. It can be paired with PWR-C1-715WAC, PWR-C1-715WAC-P and PWR-C1-1100WAC supplies in the switch power-supply bays, as shown in the Catalyst 9300 power tables.
Q: Can it be replaced while the switch is running?
A: Yes. It is a hot-swappable module with a release latch and extraction handle, so it can be changed without powering down the switch when a second supply is carrying the load.
