Cisco PWR-C1-715WAC/2 | Catalyst 3850 715W AC Power Supply, Config 1, Secondary
SKU:PWR-C1-715WAC/2
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The PWR-C1-715WAC/2 is a hot-swappable 715W AC plug-in power supply for Cisco Catalyst 3850 and Catalyst 3650 switches. The /2 suffix identifies the secondary power supply bay unit, so it suits campus and branch access-layer deployments that need power redundancy or a larger PoE budget.
It delivers up to 715W at -56V and 12.8A from an autoranging 100-240 VAC, 50-60 Hz input, with an input current of 10-5A. Heat output is 2465 BTU/hr. On 24-port PoE Catalyst 3850 models, one 715W supply provides 435W of PoE power. Two 715W supplies, or one 1100W plus one 715W, are needed to deliver PoE+ on all ports of a 48-port PoE switch.
Recommended cable: Blue Cable Co® C14 to C15 power cable. Its slim C15 plug fits this power supply’s cable management bracket.
The module is a Config 1 supply and works with the Catalyst 3850 range (12, 24 and 48-port AC models) and the Catalyst 3650 range. It can also be paired with the PWR-C1-1100WAC in the dual power supply bays. AC OK and PS OK LEDs on the module show input and output power status, and the input uses an IEC 320-C16 receptacle.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable, field-replaceable plug-in module
- Provides power redundancy when installed in the secondary power supply bay
- Autoranging 100-240 VAC input suits global power conditions
- Supplies 435W of PoE budget on 24-port PoE Catalyst 3850 models
- Front-panel AC OK and PS OK LEDs for quick status checks
- Interoperates with the PWR-C1-1100WAC in the dual power supply bays
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Maximum output power: 715W
- Output rating: -56V at 12.8A
- Input voltage: 100-240 VAC, autoranging, 50-60 Hz
- Input current: 10-5A
- Total output heat: 2465 BTU/hr (715W)
- Output holdup time: 16.7 ms minimum at 100 VAC
- Input receptacle: IEC 320-C16
- Power cord rating: 13A
- Dimensions (H x W x D): 1.58 x 3.25 x 12.20 in
- Weight: 2.8 lb (1.3 kg)
- Operating temperature: -5 to 45 C (23 to 113 F)
- Storage temperature: -40 to 70 C (-40 to 158 F)
- Relative humidity: 5 to 90% noncondensing
- Altitude: 3000 m (10,000 ft) up to 45 C
- MTBF: greater than 300,000 hours calculated (Telcordia SR-332)
- EMI/EMC compliance: FCC Part 15 Class A, EN 55022 Class A, CISPR 22 Class A, AS/NZS 3548 Class A, EN 55024
- Safety compliance: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
- LED indicators: AC OK and PS OK
FAQs
Q: Which switches does the PWR-C1-715WAC/2 work with?
A: It is a Config 1 power supply for the Cisco Catalyst 3850 Series (12, 24 and 48-port AC models) and the Catalyst 3650 Series.
Q: What does the /2 in the part number mean?
A: The /2 suffix denotes the secondary power supply bay unit, used for redundancy or to add to the switch's available power.
Q: How much PoE power does it provide?
A: On 24-port PoE Catalyst 3850 models, one 715W supply provides 435W of PoE power. A 48-port PoE switch needs two 715W supplies, or one 1100W plus one 715W, to deliver PoE+ on all ports.
Q: Can I mix it with a different power supply in the same switch?
A: Yes. It can be paired with the PWR-C1-1100WAC in the dual power supply bays of the Catalyst 3850.
Q: What AC input does it accept?
A: It accepts 100-240 VAC, autoranging, at 50-60 Hz, through an IEC 320-C16 input receptacle.
