Cisco N2K-B22FTS-P | Nexus B22 Fabric Extender for Fujitsu, 16x 10G, 8x SFP+

N2K-B22FTS-P

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Nexus B22F is a blade fabric extender for Fujitsu PRIMERGY BX400 and BX900 enclosures. It acts as a remote line card for a parent Cisco Nexus 5000 or 6000 switch, extending the unified fabric into the blade chassis so server access is managed from a single point.

This pre-configured bundle (-P) provides 16 internal 10GBASE-KR host interfaces to the blade servers and 8 SFP+ 10G fabric uplinks. Fabric speed is 80 Gbps in each direction (160 Gbps full duplex) with 2:1 oversubscription and hardware forwarding at 400 Gbps or 297 mpps. Ethernet and FCoE traffic share the same uplinks, and vPC is supported for fast convergence. The unit can sit up to 3 km from the parent switch (300 m for FCoE traffic).

There is no separate licence for the fabric extender itself, as its software is delivered from the parent Nexus switch NX-OS image. It is powered by the blade chassis at 12V and 6A, with a typical draw of 56 W. Uplinks accept FET-10G, SFP-10G-SR, SFP-10G-LR and SFP-10G-ER optics, plus SFP-H10GB Twinax and QSFP-4SFP10G breakout cables.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Remote line card for a parent Nexus switch, forming a distributed modular system with a single point of management
- Plug-and-play operation, automatically downloading its software image from the parent Nexus switch
- In-service software upgrade (ISSU) supported
- Carries Ethernet and FCoE traffic over the same uplinks for a unified fabric
- vPC support for fast convergence and effective use of bandwidth
- Can be mixed with Nexus 2000 Series fabric extenders under the same parent switch
- Fewer management points than discrete blade switches, simplifying operations
- Feature set derived from the parent Nexus switch

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Chassis support: Fujitsu PRIMERGY BX400 and BX900 enclosures
- Host interfaces: 16 x 10GBASE-KR (internal midplane to blade servers)
- Fabric uplinks: 8 x SFP+ 10G
- Fabric speed: 80 Gbps in each direction (160 Gbps full duplex)
- Oversubscription: 2:1
- Forwarding performance: 400 Gbps or 297 mpps in hardware
- Distance to parent switch: up to 3 km (300 m for FCoE traffic)
- Parent switch: Nexus 5000 (NX-OS 5.2(1)N1(1) and later) or Nexus 6000 (NX-OS 6.0 and later)
- Uplink optics: FET-10G, SFP-10G-SR, SFP-10G-LR, SFP-10G-ER
- Uplink cables: SFP-H10GB-CU1M/CU3M/CU5M, SFP-H10GB-ACU7M/ACU10M, QSFP-4SFP10G breakout cables
- Power supply: provided by blade chassis, 12V @ 6A
- Typical operating power: 56 W
- Maximum input power: 70 W
- Heat dissipation: 239 BTU/hour
- Dimensions (L x W x D): 267.7 x 192.79 x 27.94 mm
- Weight: 1.27 kg
- Operating temperature: 10 to 40 C
- Storage temperature: -40 to 60 C
- Humidity: 10 to 95 percent, non-condensing
- Altitude: 0 to 3000 m
- MTBF: 291,523 hours
- Regulatory: CE, UL/CSA/EN/IEC 60950, EMC Class A, RoHS 6

FAQs

Q: Does the B22F need its own licence?
A: No. The fabric extender software is embedded in the parent Nexus switch NX-OS image and managed from that switch. Feature licences on the parent switch, such as FCoE, may still apply.

Q: Which parent switches does it connect to?
A: It connects to Nexus 5000 Series switches running NX-OS 5.2(1)N1(1) or later, and Nexus 6000 Series switches running NX-OS 6.0 or later.

Q: How is the B22F powered?
A: It is powered by the Fujitsu blade chassis at 12V and 6A, with a typical draw of 56 W and a maximum of 70 W. It has no separate power supply or fan tray.

Q: Which optics and cables work on the fabric uplinks?
A: The 8 SFP+ uplinks accept FET-10G, SFP-10G-SR, SFP-10G-LR and SFP-10G-ER optics. Cisco SFP-H10GB passive and active Twinax cables and QSFP-4SFP10G breakout cables are also supported.

Q: Which Fujitsu enclosures is this model for?
A: This B22F model is for Fujitsu PRIMERGY BX400 and BX900 blade enclosures.
