Cisco

Cisco DS-CWDM-MUX8A | 8-Ch CWDM Mux/Demux | 1470–1610 nm (20 nm grid) | Monitor Ports | SMF LC duplex | Passive

SKU:DS-CWDM-MUX8A

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Passive 8-channel CWDM multiplexer/demultiplexer that aggregates wavelengths from 1470 to 1610 nm onto a single SMF pair. Includes monitor ports for non-intrusive optical power measurement and works with CWDM SFP/SFP+ optics per ITU-T G.694.2. Ideal for SAN, metro, and campus fiber consolidation.

Features

- Eight CWDM channels across 1470–1610 nm for efficient fiber utilization
- Integrated monitor ports for non-intrusive troubleshooting and performance checks
- Passive design with zero power consumption and high reliability
- Standards-based CWDM grid for broad optics interoperability
- LC duplex interface for easy integration with existing SMF infrastructure

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Can I use this with CWDM SFP and SFP+ transceivers?
A: Yes. It supports CWDM optics operating on the 1470–1610 nm wavelengths as defined by ITU-T G.694.2. Ensure the link budget meets your distance and loss requirements.

Q: Do I need one unit at each end of the link?
A: Yes. For full-duplex links over a fiber pair, deploy a CWDM mux/demux at both ends.

Q: What fiber type is required?
A: Single-mode OS1/OS2 fiber with LC duplex connectors.

Q: What are the monitor ports used for?
A: They provide a low-percentage optical tap for service-safe measurements with an optical power meter or OSA.

Q: Can different data rates share the same CWDM system?
A: Yes. CWDM multiplexes by wavelength, so mixed protocols and speeds can coexist provided each uses a unique wavelength and budgets are met.

Technical Specifications

- Channel count: 8 (Mux/Demux)
- Supported wavelengths: 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610 nm
- CWDM grid: ITU-T G.694.2 (20 nm spacing)
- Fiber type: Single-mode (OS1/OS2, 9/125 µm)
- Connectors: LC duplex (channel and line)
- Ports: Channel ports, common line port, monitor ports for live optical measurement
- Directionality: Bidirectional (mux/demux)
- Design: Passive (no power required)
- Use case: Multiplex multiple CWDM transceiver links over a single fiber pair
- Mounting: Rack-mountable module/panel (form factor varies by installation)
