• Cisco CW9176D1-RTG white Wi-Fi 6E tri-band access point with external antennas
1 1

Cisco

Cisco CW9176D1-RTG | Wi‑Fi 6E tri‑band (2.4/5/6 GHz) | 3‑radio 4x4:4 | external antennas | 1x 5GbE mGig + 1x 1GbE | PoE 802.3bt Type 4 (Class 8) | DNA Essentials/Advantage

CW9176D1-RTG

Stock Status: Enquire

$4,534.13 AUD
$4,534.13 AUD
$4,534.13 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Tri‑band Wi‑Fi 6E access point with three 4x4:4 radios for 2.4, 5, and 6 GHz, designed for high‑density indoor networks. The D1 external‑antenna model enables precise RF shaping with sector or directional antennas for auditoriums, arenas, or warehouses. A 5GbE multigig uplink supports maximum throughput, and 802.3bt Type 4 PoE delivers full functionality; 802.3at is supported with reduced features. Built‑in UWB and BLE/802.15.4 radios support location services and IoT. Managed via Catalyst 9800 controllers and Cisco DNA subscriptions for assurance and automation.

Features

- High‑density tri‑band Wi‑Fi 6E
- External antenna design for tailored coverage
- OFDMA and MU‑MIMO efficiency
- 5GbE multigig uplink
- UWB and BLE/802.15.4 for location/IoT
- WPA3 enterprise security

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi‑Fi standard: IEEE 802.11ax (Wi‑Fi 6E), tri‑band (2.4/5/6 GHz)
- Radios/streams: 3 radios, 4x4:4 per band
- Max aggregate PHY rate: up to ~18 Gbps
- Antenna type: external antenna connectors (directional/sector options supported)
- Uplinks: 1x 100M/1/2.5/5GbE mGig (PoE‑in) + 1x 10/100/1000 Ethernet
- PoE: 802.3bt Type 4 (Class 8) recommended; 802.3at supported with feature reductions
- Management: Cisco Catalyst 9800 controllers, on‑prem or cloud‑managed policy with DNA
- Security: WPA3/WPA2, 802.1X, OWE
- IoT/location: Integrated UWB and BLE/802.15.4 radios
- Mounting: ceiling/wall mounting options (indoor)

FAQs

Q: What differentiates the RTG variant?
A: RTG denotes a regional/regulatory or shipping configuration; core hardware and capabilities remain the same.

Q: Is a controller required?
A: Yes, it is typically deployed with Cisco Catalyst 9800 controllers; it can also participate in cloud‑managed policy workflows via DNA.

Q: Which PoE class is needed for full features?
A: 802.3bt Type 4 (Class 8) is recommended for full tri‑band and feature operation.

Q: Can I use existing 1GbE cabling?
A: Yes, it operates on 1GbE, but 2.5/5GbE multigig uplink is recommended to realize full throughput.

Q: Does it support location services?
A: Yes, integrated UWB and BLE/802.15.4 enable advanced location and IoT use cases.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
