Cisco

Cisco C9800-AC-750W-R | Catalyst 9800-40 750W AC Power Supply, Reverse Air

SKU:C9800-AC-750W-R

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 750W AC power entry module is the hot-swappable power supply for the Cisco Catalyst 9800-40 Wireless Controller. It suits enterprise campus and branch wireless deployments, and works as a replacement or as a second module for power redundancy in centralised, FlexConnect and SD-Access Fabric designs.

It accepts a worldwide AC input of 90 to 264 VAC at 47 to 63 Hz, with plug-side intake airflow (the R suffix denotes reverse air). The 9800-40 chassis has two PSU slots, PEM 0 for the default supply and PEM 1 for an optional redundant supply. The chassis has a maximum power consumption of 381 W and runs continuously on a single module. Green and amber status LEDs show whether the module is healthy or has failed.

The module is designed for the Catalyst 9800-40 only, and no licence is required for the power supply itself.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable AC power entry module
- Provides redundant power when two modules are installed
- Default power supply for the Catalyst 9800-40
- Green and amber LED indicators for module status
- Wide-range AC input suited to worldwide deployment
- Controller keeps running on a single installed module

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Power rating: 750W AC
- Airflow: Plug-side intake (reverse air)
- Form: Hot-swappable power entry module
- AC input voltage: 90 to 264 VAC
- AC input frequency: 47 to 63 Hz
- Host controller: Catalyst 9800-40 Wireless Controller (1RU)
- PSU slots: PEM 0 (default) and PEM 1 (optional redundant)
- Host controller maximum power consumption: 381 W
- Host controller heat dissipation: 1300 BTU/hr
- Status indicators: Green (OK) and Amber (FAIL) LEDs
- Single-module operation: supported

FAQs

Q: Which controller does this power supply fit?
A: It is for the Cisco Catalyst 9800-40 Wireless Controller (C9800-40-K9) only.

Q: What does the R in the part number mean?
A: The R suffix denotes reverse air, meaning plug-side intake airflow. It does not stand for redundancy-ready.

Q: Can I add a second power supply for redundancy?
A: Yes. The 9800-40 has two PSU slots, PEM 0 and PEM 1, so a second hot-swappable module can be added for power redundancy.

Q: Can the controller run on one power supply?
A: Yes. The chassis can operate continuously with only one power entry module installed.

Q: What AC input does it accept?
A: It accepts 90 to 264 VAC at 47 to 63 Hz, suitable for worldwide mains supplies.

Q: Does it need a licence?
A: No licence is required for the power supply itself.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
