• Cisco Catalyst 9300 32-port line card with 30x100G QSFP28 and 2x400G QSFP-DD
1 1

Cisco

Cisco C9610-LC-32CD | Catalyst 9610 30-Port 100G Line Card, 2x 400G QSFP-DD

C9610-LC-32CD

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco C9610-LC-32CD is a high-density line card engineered for campus core and edge deployments requiring substantial 100G connectivity. It delivers 30 ports of 100G/40G via QSFP28 and 2 ports of 400G/200G/100G via QSFP-DD uplinks, with 6.4 Tbps full-duplex bandwidth per slot. Designed for the C9610R modular chassis with optimized airflow and direct compatibility with Supervisor 3 and 3XL modules, it supports advanced features including StackWise Virtual, IOS XE programmability, and unified cloud management.

Features

Native C9610R chassis design with optimized 1.25 RU form factor and enhanced airflow
- Non-blocking architecture with 6.4 Tbps full-duplex switching capacity per slot
- Supports 32 line-rate ports: 30x QSFP28 (100G/40G) + 2x QSFP-DD (400G/200G/100G/40G)
- Flexible port conversion: four QSFP28 ports can convert to two QSFP-DD ports for 400G uplinks
- Powered by Cisco Silicon One E100/K100 ASIC architecture with distributed processing
- StackWise Virtual support with up to 400G SVL links for chassis redundancy
- Hot-swappable design for non-disruptive installation and replacement
- Advanced Layer 2 and Layer 3 switching capabilities via IOS XE
- Full programmability support: NETCONF, RESTCONF, gNMI, and RESTful APIs
- Cloud-managed capabilities through Cisco Catalyst Center and Meraki dashboard
- Application hosting support on supervisor for distributed edge computing and AI/ML workloads
- In-Service Software Upgrade (ISSU) and Graceful Insertion and Removal (GIR)
- Comprehensive security features including MACsec, TrustSec, and zero-trust segmentation
- Multi-rate optics support with automatic speed negotiation
- Energy-efficient design with platinum-rated power supply compatibility

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

Port Configuration: 30 ports QSFP28 (100G/40G), 2 ports QSFP-DD (400G/200G/100G/40G)
- Total Ports: 32 ports (30 standard + 2 high-speed uplinks)
- Bandwidth: 6.4 Tbps full-duplex per slot, non-blocking architecture
- Form Factor: 1.25 RU line card module
- Chassis Compatibility: Cisco C9610R 10-slot modular chassis
- Supervisor Support: C9610-SUP-3 and C9610-SUP-3XL (both Supervisor 3 and 3XL modules)
- Slot Support: Slots 1, 2, 3, 4, 7, 8, 9, and 10
- ASIC Architecture: Distributed across four Cisco Silicon One E100/K100 ASICs
- Power Consumption: 1590W DC output (typical operating), 2.6A at 240VAC
- Heat Dissipation: 420 BTU/hr (typical), up to 466 BTU/hr maximum
- Weight: 13.89 lb (6.3 kg)
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Adapter Requirement: No adapter required (native C9610 design)
- Management: Cisco IOS XE, Cloud management via Cisco Catalyst Center, NETCONF, RESTCONF, gNMI APIs
- Optics Support: QSFP28 100GBASE and 40GBASE optics, QSFP-DD 400GBASE optics

FAQs

Q: What chassis is the C9610-LC-32CD compatible with?
A: The C9610-LC-32CD is designed specifically for the Cisco C9610R 10-slot modular chassis and requires either the C9610-SUP-3 or C9610-SUP-3XL Supervisor Engine. It can be installed in slots 1, 2, 3, 4, 7, 8, 9, or 10. Unlike C9600X series line cards, it does not require an adapter for installation.

Q: How does this line card differ from the C9600X-LC-32CD?
A: The C9610-LC-32CD is a newer version specifically optimized for the C9610R chassis with superior airflow, improved layout, and native compatibility. It delivers the same port configuration (30x 100G/40G QSFP28 + 2x 400G QSFP-DD) but requires no adapter, whereas the C9600X-LC-32CD requires the C9610-LC-ADPT adapter when used in a C9610R chassis.

Q: Can I use 400G ports for StackWise Virtual links?
A: Yes, the two QSFP-DD ports (ports 27 and 31) support 400G StackWise Virtual and DAD links. However, you must first enable StackWise Virtual mode, then use the hw-module command to enable 400G operation on these specific ports before configuring them as SVL links.

Q: What is the maximum 100G port density I can achieve with this line card?
A: With up to 8 line card slots in the C9610R chassis, you can achieve up to 240 ports of 100G (30 ports × 8 cards) plus 16 additional 400G uplink ports, providing massive scalability for high-density campus core deployments.

Q: What licensing model does this line card require?
A: The C9610-LC-32CD operates under the Cisco Networking Subscription unified licensing model, which includes software features, hardware support, and unified product support. The licensing is applied at the supervisor level and covers all installed line cards in the chassis.
