Aruba

Aruba S0U67A | CX 5420 24-Port 1G SFP Line Card, Non-TAA

SKU:S0U67A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The CX 5420 24p SFP 1G Module is a half-width, 24-port SFP line card for the modular Layer 3 CX 5420 chassis switch. It adds fibre-based 1GbE access or aggregation ports to the 6-slot chassis and is not a standalone switch. It suits campus and enterprise fibre access, small core and aggregation deployments where SFP connectivity is needed in a modular platform.

The module provides 24 SFP ports supporting 1GbE, with 100M fibre also available through SFP accessories such as a 100M FX optic. Maximum bandwidth is 24 Gb/s, and all ports support MACsec. Maximum power draw is 51 W, and the module provides no PoE. This is the non-TAA variant, part number S0U67A.

It fits the half-width line card slots of the CX 5420 6-slot chassis together with the S0U55A management module and S0U54A fan tray. The module needs no licence of its own and runs under the AOS-CX operating system of the host chassis. It measures 214.7 x 212.2 x 45.15 mm and weighs 0.90 kg.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Modular Layer 3 chassis platform with BGP, OSPF, VSX and robust QoS
- Gen7 ASIC architecture with up to 960 Gbps non-blocking chassis bandwidth
- VSX live upgrades for high availability
- MACsec encryption supported on all ports
- Unsupported Transceiver Mode allows unsupported 100M to 25G transceivers to be enabled
- Network Analytics Engine for monitoring and troubleshooting
- Dynamic Segmentation for consistent wired and wireless role-based policy
- Management via Aruba Central or HPE Mist

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Ports: 24 x SFP
- Port speeds: 1GbE, 100M fibre via SFP accessories
- Maximum bandwidth: 24 Gb/s
- Form factor: Half-width line card
- Per-slot forwarding in chassis: up to 160 Gb/s, line rate at 64 bytes
- MACsec: supported on all ports
- PoE: none
- Power consumption (max): 51 W
- Dimensions (H x W x D): 45.15 x 214.7 x 212.2 mm
- Weight: 0.90 kg
- Chassis switching capacity (CX 5420 6-slot): 960 Gbps
- Chassis throughput: 714 Mpps
- Chassis latency (64-byte): 2.5 microseconds
- Chassis operating temperature: 0 to 45 C
- Chassis airflow: front to back
- Laser safety: IEC 60825-1 Class 1
- Emissions: Class A (FCC Part 15B, CISPR 32, AS/NZS CISPR 32)

FAQs

Q: Does this module need its own licence?
A: No. The module runs under the AOS-CX operating system of the host CX 5420 chassis. An optional term-based CX Advanced Feature Pack subscription unlocks advanced visibility and security use cases, and Aruba Central management requires a Central subscription.

Q: Which chassis does it fit?
A: It fits the half-width line card slots of the CX 5420 6-slot chassis (S0U59A, S0U60A and the TAA variants), used with the S0U55A management module and S0U54A fan tray.

Q: Which SFP optics work with it?
A: Supported SFPs include J9054D (100M FX, 2km), J4858D (1G SX), J4859D (1G LX, 10km), J4860D (1G LH, 70km), J8177E (1G RJ45 Cat5e), and the TAA parts JL745A, JL746A and JL747A.

Q: Does it provide PoE?
A: No. This is a non-PoE module. It draws up to 51 W from the chassis, which is powered by up to four hot-swappable S0U53A 1600 W AC power supplies.

Q: How does S0U67A differ from S0U77A?
A: S0U67A is the non-TAA version. S0U77A is the TAA-compliant equivalent of the same 24-port SFP 1G module.
