Aruba S0U66A | CX 5420 16-Port 1/2.5/5G Class 6 PoE Line Card
SKU:S0U66A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This line card is built for the modular 6-slot CX 5420 chassis switch and adds 16 multi-gigabit Smart Rate RJ-45 ports to the system. It suits small and medium campus and branch networks that need to power Wi-Fi 6/6E/7 access points and PoE IoT devices over copper at access, small core or aggregation layers.
Each port runs at 1, 2.5 or 5 Gbps and delivers Class 6 PoE, up to 60W per port. The card provides up to 160 Gbps of forwarding per line card slot at line rate with 64-byte packets, and the chassis supports IEEE 802.3af, 802.3at and 802.3bt PoE. The available PoE budget depends on the number of power supplies, management modules, line cards and fan trays installed. This is the non-TAA version of the 16-port Class 6 PoE module.
It fits the open line card slots of the CX 5420 6-slot Switch (S0U59A) and the 6-slot Chassis (S0U60A). A CX 5420 Management Module (S0U55A or S0U58A TAA) and at least one S0U53A power supply are required. The card runs AOS-CX, with an optional term-based Advanced Feature Pack subscription for advanced visibility and security.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Part of the modular CX 5420 Layer 3 chassis with BGP, OSPF, RIP, PIM, VSX and robust QoS
- VSX live upgrades for non-disruptive upgrades and high availability
- Built-in analytics and automation with Network Analytics Engine (NAE)
- Management via HPE Aruba Networking Central or HPE Mist
- Dynamic Segmentation with role-based policy across wired and wireless
- Energy Efficient Ethernet (802.3az) and pre-standard PoE detection
- Hot-swappable power supplies with N+1 and N+N redundancy
- Auto-MDIX on 10/100/1000 and Smart Rate ports
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Module type: I/O line card for CX 5420 6-slot chassis
- Ports: 16 x 1/2.5/5GBASE-T Smart Rate RJ-45
- PoE class: Class 6, up to 60W per port
- PoE standards supported by chassis: IEEE 802.3af, 802.3at, 802.3bt (up to 90W)
- Forwarding per line card slot: up to 160 Gbps, line rate at 64 bytes
- Chassis switching capacity: 960 Gbps
- Chassis throughput: 714 Mpps
- Average latency (64-byte packets): 2.5 micro sec
- Packet buffer: 64MB shared dynamically among ports
- Chassis line card slots: 6 open line card slots plus 1 management slot
- Chassis power supplies: up to 4 hot-swappable S0U53A 1600W AC
- Airflow: Front to back
- Operating temperature (chassis): 0 to 45 C
- Operating relative humidity: 5% to 95% at 45 C, non-condensing
- Non-operating temperature: -40 to 70 C
- Max operating altitude: 10,000 ft (3 km)
- Chassis dimensions (H x W x D): 17.41 x 44.25 x 44.74 cm
- Chassis configuration weight: 15.73 kg
- Jumbo frames: up to 9198 bytes
- LACP: up to 144 LAGs, up to 16 links per LAG
- Emissions: Class A (FCC Part 15B, EN 55032, AS/NZS CISPR 32)
FAQs
Q: Does this line card need a licence?
A: No. It runs AOS-CX, which includes the native feature set. An optional term-based CX 54XX Advanced Feature Pack subscription unlocks advanced visibility and security, and it is not needed if HPE Aruba Networking Central Advanced is used.
Q: What PoE does each port deliver?
A: Each port delivers Class 6 PoE, up to 60W. The total PoE budget depends on the number of S0U53A power supplies, management modules, line cards and fan trays installed in the chassis.
Q: Which chassis and parts does it work with?
A: It fits the open line card slots of the CX 5420 6-slot Switch (S0U59A) and the 6-slot Chassis (S0U60A). It needs a CX 5420 Management Module (S0U55A or S0U58A TAA) and at least one S0U53A 1600W AC power supply.
Q: How does this differ from S0U76A?
A: This SKU is the non-TAA version of the 16-port Smart Rate Class 6 PoE module. S0U76A is the TAA-compliant equivalent.
Q: What speeds do the ports support?
A: The 16 RJ-45 Smart Rate ports run at 1, 2.5 or 5 Gbps over copper, with Auto-MDIX support.
