• Gray arista dcs-7800-sup 7800r3 supervisor module back side with circular power button ethernet usb ports and status lights
1 1

Arista

Arista DCS-7800-SUP | 7800R3 Supervisor Module, 1.9GHz 6-Core, 64GB RAM

DCS-7800-SUP

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7800R3 supervisor module is the control-plane engine for the 7804 and 7808 modular chassis in the 7800R3 series. It runs Arista EOS and handles all control plane and management functions for the chassis. Each chassis has two supervisor slots, so a second supervisor can be fitted for 1+1 redundancy.

This module is built around a 1.9 GHz six-core 64-bit x86 processor with 64 GB of system memory and 4 GB of flash storage. It draws 61 W typical and 72 W maximum, supplied from the chassis power supplies. It measures 2.1 in x 9.0 in x 17.25 in (5.3 x 22.8 x 43.8 cm) and weighs 6.3 lbs (2.9 kg).

It is designed for the 7804 and 7808 chassis. The 7816 chassis uses different supervisor variants, and the SUP1A and SUP1S are sibling modules for the same chassis, so confirm the part number against your chassis before ordering.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Runs Arista Extensible Operating System (EOS)
- Handles all control plane and management functions for the chassis
- Supports 1+1 supervisor redundancy with a second supervisor
- Six-core x86 CPU with 64 GB DRAM
- Optional SSD for additional storage
- Powered from the chassis power supplies

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Product type: Supervisor module
- Chassis compatibility: 7804 and 7808
- Supervisor slots per chassis: 2
- Processor: 1.9 GHz six-core x86, 64-bit
- System memory: 64 GB
- Flash storage: 4 GB
- Typical power: 61 W
- Maximum power: 72 W
- Dimensions (H x W x D): 2.1 in x 9.0 in x 17.25 in (5.3 x 22.8 x 43.8 cm)
- Weight: 6.3 lbs (2.9 kg)
- Operating system: Arista EOS

FAQs

Q: Which chassis does this supervisor module fit?
A: It is designed for the Arista 7800R3 series 7804 and 7808 chassis. The 7816 chassis uses different supervisor variants.

Q: Can I run two supervisors for redundancy?
A: Yes. Each 7804 and 7808 chassis has two supervisor slots. One supervisor runs the system and a second can be added for 1+1 redundancy.

Q: How much power does the supervisor draw?
A: It draws 61 W typical and 72 W maximum, supplied from the chassis power supplies.

Q: What software does the supervisor run?
A: It runs Arista EOS, which provides the control plane and management functions for the chassis.

Q: How does this differ from the SUP1A and SUP1S modules?
A: The DCS-7800-SUP1A and SUP1S are sibling supervisor modules for the same chassis. This SKU has a 1.9 GHz six-core processor, 64 GB of RAM and 4 GB of flash.
