• Arista dcs-7508e-fm enterprise network switch with sleek gray metal chassis and multiple rows of ethernet ports
1 1

Arista

Arista DCS-7508E-FM | 7500E Fabric Module for 7508E Chassis, 155W, 5+1

DCS-7508E-FM

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7500E Fabric Module is the Fabric-E module with an integrated fan assembly for the 8-slot 7508E modular data centre switch chassis. It interconnects every line card in the chassis and is aimed at large data centre spine and core deployments built on the Arista 7500E Series, where the 7508E chassis supports up to 30 Tbps of throughput.

Each module provides 5.12 Tbps of non-blocking fabric capacity and operates in a 5+1 redundant configuration across the six fabric module slots in the chassis. Fabric modules are always active-active with N+1 redundancy, and typical power draw is 155W with a 195W maximum per module. The fan assembly is integrated, giving flexible and redundant cooling. This SKU is specific to the 8-slot 7508E chassis.

It works with the 7500E line cards (12CQ, 12CM, 36Q, 6C2, 72S, 48S and 48T) and the 7500E-SUP supervisor. It is not interchangeable with DCS-7504E-FM, which is for the 4-slot chassis. System power comes from the chassis PWR-2900AC power supplies.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Non-blocking fabric architecture connecting all line cards regardless of traffic pattern
- Always active-active fabric modules with N+1 redundancy
- Hot-swappable with zero performance degradation
- Integrated fan assembly for flexible and redundant cooling
- Packets are spread across fabric links for 100% efficient any-port-to-any-port connectivity without hash-based link selection
- Virtual Output Queueing, distributed scheduler and self-healing fabric

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: DCS-7508E-FM
- Product type: Chassis fabric module with integrated fan
- Chassis support: DCS-7508 / 7508E 8-slot chassis
- Fabric capacity per module: 5.12 Tbps
- Redundancy: 5+1 (N+1)
- Fabric module slots in chassis: 6
- Typical power (maximum): 155W (195W)
- Integrated fan module: Yes
- Dimensions (H x W x D): 2.5 in x 14 in x 10.25 in (6.4 x 35.6 x 26 cm)
- Weight: 10 lbs (4.5 kg)
- Chassis total throughput (DCS-7508): 30 Tbps / 14.4 Bpps
- Operating temperature (system): 0 to 40 C (32 to 104 F)
- Storage temperature (system): -40 to 70 C (-40 to 158 F)
- Relative humidity (system): 5 to 95%
- Operating altitude (system): 0 to 10,000 ft (0-3,000 m)
- EMI compliance (system): FCC Part 15 Class A, ICES-003 Class A, VCCI Class A
- Safety (system): IEC/UL/CSA/EN 60950, CE, UL, cTUVus, TUV Mark
- RoHS compliant (system)

FAQs

Q: Does this fabric module need a licence?
A: No licence is listed for the fabric module itself. It is a hardware component of the 7500E chassis.

Q: Which chassis does it fit?
A: It is for the Arista DCS-7508 / 7508E 8-slot chassis only. It is not interchangeable with DCS-7504E-FM, which is for the 4-slot chassis.

Q: How much power does it draw?
A: Typical draw is 155W with a maximum of 195W per module, and the fan assembly is integrated. System power comes from the chassis PWR-2900AC power supplies.

Q: Which line cards and supervisor does it work with?
A: It supports the 7500E line cards (12CQ, 12CM, 36Q, 6C2, 72S, 48S and 48T) and the 7500E-SUP supervisor.

Q: How many fabric modules does the chassis use?
A: The 7508E chassis has six fabric module slots and runs in a 5+1 redundant configuration. This module is required for fabric slots 1-6.
