Arista CCS-758-X3-SC | 750X 8-Slot Switch Card, 1.6Tbps, 850Mpps
SKU:CCS-758-X3-SC
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The CCS-758-X3-SC is the switch card for the Arista 750X Series CCS-758 8-slot, 10RU modular campus chassis. It handles all packet processing for L2 and L3 forwarding, QoS, security policy, VXLAN and EVPN segmentation, and is aimed at large enterprise campus core and distribution networks that need high availability.
This 8-slot variant delivers 1.6Tbps of switching throughput and 850Mpps forwarding, with a shared 32MB packet buffer and up to 160K MAC addresses. It operates in a 1+1 active/standby arrangement with SSO, so a failed card does not interrupt campus spines and splines. Typical power draw is 101W, rising to 174W at maximum. The card itself needs no licence, while the CCS-758 system uses the LIC-MOD-G EOS licence group and the MOD-G CloudVision group.
It is designed for the CCS-758 8-slot chassis only, and works with the CCS-750-SUP100 and CCS-750-SUP25 supervisors and the 750X series 48-port PoE and non-PoE linecards. EOS 4.25.1 or later is required.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Non-blocking, hot-swappable switch card with 1+1 active/standby redundancy and SSO
- Hitless communication with campus spines and splines through active/standby switch cards
- Handles all packet processing for L2/L3 forwarding, QoS, security policy, VXLAN and EVPN segmentation
- Fully shared 32MB packet buffer to absorb bursts and speed changes
- Independent control plane and data plane across the chassis
- Runs Arista EOS with CloudVision management, ZTP and LANZ microburst detection
- Built-in 802.1AE MACsec on all ports at system level
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Switch Card model: CCS-758-X3-SC (8-slot chassis)
- Switching throughput: 1.6Tbps
- Forwarding rate: 850Mpps
- Redundancy: 1+1 Active / Standby
- Typical power (maximum): 101W (174W)
- Integrated packet buffer memory: 32MB
- MAC entries: 160K max
- Virtual ports: 32K
- Virtual forwarding instances (VFI): 16K
- VLANs: 4K for uplinks; 16K sum of (port, vlan) combinations for downlinks
- VLAN translation: 8K ingress and 8K egress
- MAC-based VLANs: 8K
- Scalability Mode 2 (default): 160K MAC addresses, 160K IPv4 host routes, 32K IPv4 LPM routes, 160K IGMP groups, 80K IPv4 L3 multicast
- Security ACL entries (ingress/egress): 16K/6K
- Dimensions (WxHxD): 41.2 x 10.3 x 21.9 cm
- Weight: 5.4 kg
- Minimum EOS: 4.25.1
- EOS licence group: LIC-MOD-G
- CloudVision licence group: MOD-G
- Operating temperature (system): 0 to 40 C
- Storage temperature (system): -40 to 70 C
- Relative humidity (system): 5 to 90%
- Operating altitude (system): 0 to 3,000 m
FAQs
Q: Does this switch card need a licence?
A: No, the card itself needs no licence. The CCS-758 system uses the LIC-MOD-G EOS licence group and the MOD-G CloudVision group. Optional platform licences include LIC-MOD-G-FLX-L, LIC-MOD-G-E, LIC-MOD-G-V2 and LIC-MOD-G-MACSEC.
Q: Which chassis does the CCS-758-X3-SC fit?
A: It is for the CCS-758-CH 8-slot, 10RU chassis only. The 5-slot CCS-755 chassis uses the CCS-755-X3-SC.
Q: What power does it draw from the chassis?
A: It draws 101W typical and 174W maximum. The CCS-758 chassis takes up to 10 hot-swap PWR-3351-AC-RED 3300W AC PoE power supplies, with 5 recommended and 1 as the minimum.
Q: What supervisors and linecards does it work with?
A: It works with the CCS-750-SUP100 and CCS-750-SUP25 supervisors and the 750X series 48-port PoE and non-PoE linecards. EOS 4.25.1 or later is required.
Q: How does the redundancy work?
A: Switch cards run in a 1+1 active/standby arrangement with SSO. If the active card fails, the standby card takes over without interrupting traffic.
