Meraki POE-INJ-3-AU | Gigabit 802.3af PoE Injector, 15.4W, AU Plug

POE-INJ-3-AU

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This single-port Gigabit PoE injector sends power and data to a connected device over one Ethernet cable, so no separate power cabling is needed at the device. It is aimed at powering Meraki access points and other 802.3af PoE devices where no PoE switch port is available or where running power cabling is difficult.

The injector is IEEE 802.3af compliant and supplies up to 15.4W of PoE output. Data passes at 10/100/1000 Mbit/s full duplex, and the connected device can sit up to 100m from the injector. It has one LAN data-in port and one PoE out port. Over-voltage, over-current and short-circuit protection is built in, and power, load and fault LEDs make diagnosis straightforward. This version is the AU plug variant and connects directly to Australian mains outlets.

Because output is limited to 15.4W, it suits devices that need 802.3af. Devices that require 802.3at or 802.3bt need a higher-power injector. No licence is required for the injector itself.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Powers a device over a single Ethernet cable, removing the need for separate power cabling
- Powers devices up to 100m from the injector
- Fully compliant with the 802.3af PoE standard
- Gigabit compatible for full-speed data
- Over-voltage, over-current and short-circuit protection
- Power, load and fault diagnostic LEDs

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Standard: IEEE 802.3af compliant
- PoE output: 15.4W maximum
- Data rates: 10/100/1000 Mbit/s (full duplex)
- Maximum power distance: up to 100m from the injector
- Ports: 1 x data in (LAN), 1 x PoE out
- Protections: over-voltage, over-current, short-circuit
- Diagnostic LEDs: power, load, fault
- Plug type: AU (Australian mains plug)

FAQs

Q: Does this PoE injector need a licence?
A: No. No licence is required for the injector itself.

Q: Can it power 802.3at or 802.3bt devices?
A: No. It supplies up to 15.4W under 802.3af, so it will not power devices that need 802.3at or 802.3bt. The 802.3at injector, MA-INJ-4, is the higher-power option.

Q: How far can the powered device be from the injector?
A: The connected device can be up to 100m from the injector over Ethernet cable.

Q: What does the AU plug mean?
A: The AU in the SKU indicates the Australian mains plug variant. The same injector is also made in US, EU and UK plug versions.

Q: Does it work at Gigabit speeds?
A: Yes. The injector passes data at 10/100/1000 Mbit/s full duplex.
